1. Login to the Maestro web interface. See the previous page for more information.
2. Click the Network tab and then select either AV Port 1 & 2 or AV Port 3 & 4. Note the
ZyPerMX2 only uses AV Ports 1 & 2.
3. The current network settings will be displayed.
4. Click the drop-down list, under IP Type, to select the desired network mode.
The default setting for IPType is DHCP.
Note that the ZyPerMX4 has 2 independent IP address while the ZyPerMX2 has only one IP
address. There is an IP address for AV ports 1 & 2 and a different IP address for AV ports 3 & 4.
Both addresses should be set using this procedure.
Once the ZyPerMX4/MX2 is properly configured, click the "lightbulb" icon, at
any time, to physically identify the ZyPerMX4/MX2 on the network. This will
cause the Status LED indicator on the front panel to flash rapidly for about 10
seconds.
