Basic Operation

The Maestro Web Interface

The ZyPerMX features the Maestro web interface. Maestro allows you to control and manage all
features of the ZyPerMX. To access Maestro, open a web browser and enter the IP address of
the ZyPerMX into the address bar. We recommend using Firefox or Chrome browsers.
1. Make sure that the computer used to access Maestro and the ZyPerMX encoder are on the
same network. If a network is not being used, the ZyPerMX can be directly connected to the
computer. In both cases, the ZyPerMX and the computer must be
on the same subnet.
2. Launch the web browser and enter the default IP address of 192.168.1.10 in
the address bar.
3. The Maestro interface will be displayed with the password dialog.
4. Enter the password. The default password is admin and is case-sensitive.
If you wish to have the password stored, next time Maestro is launched, click the Remem-
ber Password check box.
5. Click the Login button.

Logging In

4

Network Configuration

1. Login to the Maestro web interface. See the previous page for more information.
2. Click the Network tab.
3. The current network settings will be displayed.
4. Click the drop-down list, under Addr Type, to select the desired network mode.
The default setting for Addr Type is Static and uses an IP address of 192.168.1.10.
Once the ZyPerMX is aproperly configured, click the "lightbulb" icon, at any
time, to physically identify the ZyPerMX on the network. This will cause the
Status LED indicator on the front panel to flash rapidly for about 10 seconds.
