The Status page is automatically displayed after logging in to Maestro. This page displays video
and audio input/output information, firmware version, and status messages.
1. Login to the Maestro web interface. See
2. The Status tab will be selected automatically.
• The System field displays the name of the ZyPerMX4/MX2. This name can be
changed. See the next page for more information.
• Click the "lightbulb" icon to physically identify the ZyPerMX4/MX2 on the network.
When this icon is clicked, the Status LED indicator on the front panel will flash rapidly
for about 10 seconds.
• The Video field displays the video input and output resolution. In the illustration below,
the input is 720p60 and the output is 720p60. Video input and output resolution cannot
be changed. To change the video bitrate see
15).
• The Audio field displays the input audio type and the output audio type.
• The Model field displays the name of the model of the ZyPerMX4/MX2.
• The Firmware field displays the current version of firmware.
• The Uptime field displays the time, in days and hours, since the unit was last re-
booted.
• The Temp field displays the ZyPerMX4/MX2 unit internal temperature
• The Enet Average field displays current average output on the Ethernet port
• The Messages field receives messages reported by the ZyPerMX4/MX2, during
operation.

Displaying Device Information

Note: This field can be helpful to determine if HLS streaming level has been
reached
Logging In (page 3) for more information.
Adjusting Audio and Video Settings (page
