Quad ZyPer4K Encoder Card
for Netgear M4300-96X
HDMI 2.0
IP A/V DISTRIBUTION SYSTEM
PART NUMBER: Z4KNGENC4
User Manual
Updated January 2020

Advertisement

Table of Contents
loading

Related Manuals for ZeeVee Quad ZyPer4K

Summary of Contents for ZeeVee Quad ZyPer4K

  • Page 1 Quad ZyPer4K Encoder Card for Netgear M4300-96X HDMI 2.0 IP A/V DISTRIBUTION SYSTEM PART NUMBER: Z4KNGENC4 User Manual Updated January 2020...
  • Page 2 RF coax, fiber, or copper ethernet. Established in 2007, ZeeVee has been manufacturing industry-leading products while operating the company responsibly in compliance with the strictest levels of regulatory and environmental requirements.

  • Page 3: Table Of Contents

    CONTENTS Encoder Function ................. Quad Encoder for Netgear M4300-96X ..........Package Contents ................Installation Instructions and Notes ............ Product Limitations ................Setting up ZyPer4K in Many to Many Environment ......ZyPer Management Platform ............... Netgear M4300-96X ..................Device Technical Specifications ............

  • Page 4: Encoder Function

    ZyPer4K Encoder Function The function of the ZyPer4K Encoder Device (Encoder) is to accept audio and video data over a variety of interface types, and translate that data to a format suitable for transmission over a standard 10Gb Ethernet network. The encoder supports inputs up to 4K resolution including full HDMI 2.0 support.

  • Page 5: Package Contents

    ZyPer4K Port Name Index Definition IR-OUT Infrared Commands passed back FROM decoders as configured by ZMP. IR-OUT Infrared Commands passed back FROM decoders as configured by ZMP. IR-OUT Infrared Commands passed back FROM decoders as configured by ZMP. IR-IN Infrared Commands to be passed TO decoders as configured by ZMP. RESET Hardware Reset pin.

  • Page 6: Installation Instructions And Notes

    ZyPer4K Installation Instructions and Notes The Z4KNGENC4 card is only compatible with the Netgear M4300-96X switch. The following instructions should be followed closely to avoid damaging the card or the switch itself. Prior to installation of the card, please ensure the latest available firmware is installed on the Netgear M4300-96X switch.

  • Page 7: Setting Up Zyper4K In Many To Many Environment

    ZyPer4K Setting up ZyPer4K in Many to Many Environment A many to many, or switched environment involves connecting many sources to many displays. ZyPer4K allows you a flexible and scalable amount of input-output options without limitations.
 For example, in a 24-port configuration, you can configure a 1x23, 6x18, or 4x20 (and so on) system.
  • Page 8 ZyPer4K • Switch (or route) video from sources to displays • Drag source onto display to route video/audio IP Address of MP Drag and Drop Z4K Quad Encoder Page...

  • Page 9: Zyper Management Platform

    ZyPer4K ZyPer Management Platform Each Z4KNGENC4 card installed in the system will show up as 4 independent ZyPer4K encoders in the ZyPer Management Platform. By default each encoder will be identified by its unique MAC address. Example MAC: 80:1F:12:5D:8E:AB Port MAC addresses can be found labeled on the underside of the card. Ports are numbered from left to right.

  • Page 10: Netgear M4300-96X

    ZyPer4K Netgear M4300-96X The Z4KNGENC4 will automatically be detected by the Netgear M4300-96X switch. Media type will appear as HDMI as shown in the image below:
 Z4K Quad Encoder Page...

  • Page 11: Device Technical Specifications

    ZyPer4K Device Technical Specifications Encoder HDMI Video Specifications All encoders have one exposed HDMI port. HDMI ZyPer4K ✓ HDMI Standard Port HDMI 2.0 with HDR* and HDCP 2.2 Support ✓ Direction Input ✓ Type-A receptacle (female) Connector ✓ Supports all major VESA resolutions and variations HDMI Resolutions including full HDMI 2.0 and HDR* support: 640x480...

  • Page 12: Physical And Environmental

    ZyPer4K Physical and Environmental The following parameters apply to the Z4KNGENC4 Quad Encoder Card. Type Parameter Dimensions 210mm x 67mm x 37mm (Quad Input Encoder Card) (LxWxH) maximum envelope Weight 405g Z4KNGENC4 (Quad Input Encoder Card) Operating 0° C to +50° C (32° F to 104° F) Temperature Non-Operating -20°...

  • Page 13: Resetting The Z4Kngenc4 Card

    ZyPer4K Appendix A Resetting the Z4KNGENC4 Card The process to completely reset the Z4KNGENC4 card comprises multiple steps as detailed below: Note the Netgear M4300-96X remains powered on for all of these steps. 1. Remove the Z4KNGENC4 from the Netgear M4300-96X switch 2.

  • Page 14: Disclaimers

    ZeeVee hardware designs are property of ZeeVee. Components, sub-assemblies, and methods utilized in the designs are free of any encumbrances or appropriate licenses and rights have been obtained by ZeeVee for the use in the described products in the intended manner.
