7. Click the Apply button to save the changes or click the Reset button to discard
any changes.
Basic Operation
12

Displaying Device Information

The Status page is automatically displayed after logging in to Maestro. This page displays
network, video and audio input/output information, firmware version, and status messages.
1. Login to the Maestro web interface. See
information.
2. The Status tab will be selected automatically.
• The System field displays the name of the ZyPerMX. This name can be changed. See
the next page for more information.
• Click the "lightbulb" icon to physically identify the ZyPerMX on the network. When this
icon is clicked, the Status LED indicator on the front panel will flash rapidly for about
10 seconds.
• The Video field displays the video input and output resolution. In the illustration above,
the input is 1080p60 and the output is 1080p60. Video input and output resolution can-
not be changed. To change the video bitrate see
(page 15).
• The Audio field displays the input audio type and the output audio type. In the illustra-
tion above, the input is LPCM and the output is LPCM. To change the output audio
type, see Adjusting Audio and Video Settings (page
•
•
•
•
• The Model field displays the name of the model of the ZyPerMX.
• The Firmware field displays the current version of firmware.
• The Uptime field displays the time, in days and hours, since the unit was last re-
booted.
• The Messages field receives messages reported by the ZyPerMX, during
operation.
Basic Operation
The Maestro Web Interface (page 4) for more
Adjusting Audio and Video Settings
10).
13
