Lay the Monitor face down on a flat, level surface.
2.
Align the Mounting Holes on the VESA Mount with the
3.
Screw Holes on the back of the Monitor, making sure that
the Mounting Flange on the VESA Mount is at the top.
Align the Washers (x 4) with the Mounting Holes on the
4.
VESA Mount.
Insert the Screws (x 4) through the Washers and Mounting
5.
Holes and into the Screw Holes in the back of the Monitor.
Using a Phillips Head Screwdriver (sold separately) tighten
6.
the Screws, being careful not to over-tighten.
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Installing the VESA Mount
25
