Mounting the Monitor Arm
Using the C-Clamp
Insert the Pole Cap into the top of the Pole.
1.
Slide the Cable Management Clips onto of the pole.
2.
- or -
Clip the Cable Management Clip onto the Pole.
Align the three Screw Holes on the top of the C-Clamp with
3.
the three Screw Holes on the bottom of the Pole.
Insert the three Pole Assembly Screws through the Screw
4.
Holes on the top of the C-Clamp and into the Screw Holes
on the bottom of the Pole.
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Installing the Pole Cap
Installing Cable Management Clip
