Mount the Access Point Using the WS-MBI-DCFLUSH
Bracket to a Flat T-bar
2. Open the movable sliding part of the bracket to give the stationary and slider T-bar more space.
Figure 13: Install the WS-MBI-DCFLUSH bracket
Callout
1
2
3. Hook the stationary end of the T-bar bracket onto the T-bar.
4. Tilt the T-bar up slightly in such a way that you are holding the stationary and movable sides of the
bracket.
5. Squeeze the bracket parts together until you hear the T-bar locking tab click into place.
28
ExtremeWireless™ AP510i Access Point Installation Guide
Description
T-bar
Movable sliding part of the DC-FLUSH bracket
Installation Process
