- Page 1 ™ ™ ExtremeWireless WiNG AP-7612 Installation Guide 9035058 Published October 2017...
- Page 2 Copyright © 2017 Extreme Networks, Inc. All rights reserved. Legal Notice Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.
-
Page 3: Table Of Contents
Table of Contents Preface............................4 Text Conventions...................................4 Providing Feedback to Us..............................4 Getting Help.....................................5 Extreme Networks Documentation..........................5 Chapter 1: Overview........................6 Uplink and Power Connections............................6 Chapter 2: Installation Process....................8 Verifying the Box Contents.............................. 8 Safety Guidelines.................................10 Mounting the Bracket to a Wall............................10 Connecting the AP to the Network.......................... -
Page 4: Preface
Preface Text Conventions The following tables list text conventions that are used throughout this guide. Table 1: Notice Icons Icon Notice Type Alerts you to... General Notice Helpful tips and notices for using the product. Note Important features or instructions. Caution Risk of personal injury, system damage, or loss of data. -
Page 5: Getting Help
Preface If you would like to provide feedback to the Extreme Networks Information Development team about this document, please contact us using our short online feedback form. You can also email us directly at internalinfodev@extremenetworks.com. Getting Help If you require assistance, contact Extreme Networks using one of the following methods: •... -
Page 6: Chapter 1: Overview
Overview Uplink and Power Connections The AP7612 (AP-7612-680B30-xx) is a wall-plate 11ac Wave 2 access point (AP) that lets you extend your wireless LAN and deploy local WiFi while still providing extension for wired clients from the same Ethernet jack. This fully-featured AP plugs into existing Ethernet cabled wall plates. he AP provides application visibility and control and policy support over dual integrated radios and a Bluetooth Low Energy (BLE) radio. - Page 7 Overview • GE2 port is used for connecting to an IP Phone. Note Both GE1 and GE2 ports are not accessible when the AP is mounted on to a bracket. GE1 acts as the building and system connection. The GE2 port provides optional power and connectivity to wired devices such as IP Phones.
-
Page 8: Chapter 2: Installation Process
Installation Process Verifying the Box Contents Safety Guidelines Mounting the Bracket to a Wall Connecting the AP to the Network Mounting the AP to the Bracket Follow these procedures to install the AP-7612: Verify the box contents. 2 Review the Safety Guidelines. - Page 9 Only the RJ45 flat cable ships with the product. Users need to provide their own additional cable for GE2. 2 Perform a visual inspection of the AP for any signs of physical damage. Contact Extreme Networks if there are any signs of damage.
-
Page 10: Safety Guidelines
Installation Process Safety Guidelines This section contains notices that you must adhere to ensure your personal safety and to prevent any damage to the equipment. Caution The unit and all interconnected equipment must be installed indoors within the same building, including all -powered network connections as described by Environment A of the IEEE 802.3at standard. - Page 11 Installation Process Figure 2: AP-7612 Mounting Bracket Number Description AP mounting tabs To mount the bracket to a wall: ExtremeWireless™WiNG™ AP-7612 Installation Guide...
-
Page 12: Connecting The Ap To The Network
Installation Process Using the mounting bracket as a guide, choose a location where it is feasible to place the AP’s center. The location must allow the LAN cables to come out of the wall within the large rectangular hole. Place the bracket against the wall. (The captive screw will be used to lock the AP in place.) Decide which two holes to use to mount the bracket. - Page 13 Installation Process 4 Attach and tighten the Security Torx screw to the bottom of the AP so that the AP is attached to the bracket. Torque the screw to 7 in-lbs. Note If you are using the optional 12V DC-IN adapter instead pf PoE on GE1 port, then cfully insert the friction fit connector into the AP.
-
Page 14: Chapter 3: Specifications
Specifications This appendix lists the specifications for the ExtremeWireless™ Indoor Access Point AP-7612. Table 6: Specifications for the AP-7612 Item Specification AP Part Number: 37101 AP-7612-680B30-US AP Part Number: 37102 AP-7612-680B30-WR Enclosure material AP enclosure is not plenum rated. Power source Power is provided by Power-over-Ethernet (802.3at or 802.3af). -
Page 15: Chapter 4: Regulatory Information
Regulatory Information United States Canada European Waste Electrical and Electronic Equipment (WEEE) Notice CE Statement for Mobile Device Usage Hazardous Substances Declaration of Conformity in Languages of the European Community United States FCC Declaration of Conformity Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 16: Canada
Regulatory Information FCC Radiation Exposure Statement For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible. This device is going to be operated in 5.15~5.25GHz frequency range, it is restricted in indoor environment only. This device is restricted for indoor use. This equipment complies with FCC RF radiated exposure limits set forth for an uncontrolled environment. -
Page 17: European Waste Electrical And Electronic Equipment (Weee) Notice
Regulatory Information 3 Les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux; 4 le gain maximal d’antenne permis pour les dispositifs utilisant les bandes 5250-5350 MHz et 5470-5725 MHz doit se conformer à... -
Page 18: Ce Statement For Mobile Device Usage
Regulatory Information The symbol above indicates that separate collection of electrical and electronic equipment is required. 2 When this product has reached the end of its serviceable life, it cannot be disposed of as unsorted municipal waste. It must be collected and treated separately. 3 It has been determined by the European Parliament that there are potential negative effects on the environment and human health as a result of the presence of hazardous substances in electrical and electronic equipment. -
Page 19: Hazardous Substances
Declaration of Conformity in Languages of the European Community Hereby, Extreme Networks, Inc. declares that the radio equipment type AP- 7612 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following Internet address: www.extremenetworks.com... - Page 20 Regulatory Information ExtremeWireless™WiNG™ AP-7612 Installation Guide...
- Page 21 Regulatory Information 5GHz band (W52, W53): Indoor Use Only NCC Statement ExtremeWireless™WiNG™ AP-7612 Installation Guide...
