Installation Process
Mount the Access Point to a Suspended or Drop Ceiling
About This Task
For suspended ceiling or drop ceiling installation, the main mounting bracket is used directly on the T-
bar. If there is a ceiling tile protrusion, the optional T-bar adapter is attached to the main mounting
bracket prior to T-bar installation.
The access point may be mounted to a suspended or a drop ceiling using:
•
#37201, stainless-steel main mounting bracket to a flat 15/16 in. wide T-bar, with flat ceiling tiles
•
#37201, stainless-steel main mounting bracket with KT-135628-01 adapter to a flat T-bar
•
#37211, WS-MBI-DCFLUSH bracket to a flat T-bar, with flat ceiling tiles
•
#30518, WS-MBI-DCMTR01 bracket to a T-bar
Mount the Access Point Using the Main Mounting Bracket to a Flat T-bar
About This Task
The AP can be mounted on a T-bar using the main mounting bracket that is shipped with the unit.
Before You Begin
•
T-bar width must be 15/16
•
T-bar bottom must be flat all the way across
•
T-bar minimum base thickness: N/A; must be structurally sound
•
T-bar maximum base thickness: 0.055 in.
•
Ceiling tile must be flat all the way across
Mount the Access Point to a Suspended or Drop Ceiling
th
inches wide (24 mm)
ExtremeWireless™ AP510i Access Point Installation Guide
25
