Installation Process
Figure 8: Mounting the AP using the WS-MBI-WALL04 Bracket
•
Use the WS-MBI-WALL04 as a template and mark the holes to be used to mount the AP. It is
recommended to use the holes marked "A" or "B".
•
Drill the holes and attach the bracket using the screws and screw-in anchors.
Note
When using the "A" or "B" holes, if the holes are not near the corners of the bracket, you
can break off the corner to decrease the bracket's visibility once the AP is installed.
ExtremeWireless™ AP510i Access Point Installation Guide
Mount the Access Point to a Wall Using an Optional Wall
and Box Bracket
