Installation Process
Install a Security Torx Locking Screw
Details about how to install the secuirity torx locking screw on the access point.
About This Task
The security torx locking screw is used to prevent the access point from being removed from the main
mounting bracket (#37201). There are two security lock screw holes on the rear of the access point.
Follow this procedure to install the security torx locking screw using one of the security lock holes on
the access point.
Note
Perform this task after the access point is attached to the main mounting bracket on a drywall
or wood wall.
Procedure
1. Line up the security torx locking screw using the rear guides on the access point.
2. Using a T10 bit screwdriver, tighten the security torx locking screw.
Mount the Access Point to a Wall using the Main
ExtremeWireless™ AP510i Access Point Installation Guide
Mounting Bracket
19
