Webasto Transit Vancouver Standard Manual page 21

Ford Transit
18. Route the wiring harness down the left-rear
corner of the body, following the same
routing as the A/C hoses.
NOTE: Any extra harness length can be
secured to the vehicle as needed.
NOTE: Be sure the relay- and fuse-mounting
screws will not penetrate the outer sheet
metal.
19. Mount the relay strip to the vehicle using two
self-tapping screws (12). Mount the fuse block
to the vehicle using one self-tapping screw
(24). Route the wiring harness over the wheel
well.
NOTE: The refrigerant valve connector is not
polarity sensitive.
20.Remove the screw from the refrigerant valve
connector and remove the connector plate.
Connect the appropriate wires to terminals 1
and 2; the ground terminal is not used.
21
Vancouver
