Parts Required For Electrical Installation - Webasto Transit Vancouver Standard Manual

Vancouver
Item Part Number
Number
6 5012357
12 902006
24 5011929
2 5012113
33 5000534
35 629069011
8 620406
23 5001085
22 5011556
19 62U001AA020B
27 62U003AA093
21 5011593
20 5011928
38 62907001

Parts required for Electrical Installation

Wiring Harness Vancouver Transit
Self Tapping Screw
Self Tapping Screw
Control Head Assy A/C Only
Screw Pan Head
Drain Tee
Cable Tie 11 inch
Cable Tie Heavy Duty
Insulation Hose
Air Duct
Air Duct End-piece
Screw Self-Tapping Black
Label - Refrigerant Charge
Anti-Condensation Tape
20
Description
17.Connect the blower motor connector [1] and
the thermostat connector [2].
Ford Transit
Quantity
1
2
2
1
4
1
As needed
As needed
1
1
1
6
1
As needed
