CD820 Instant Issuance System

Load the Print Ribbon

1. Unlock the printer and open the printer supplies access door (multi-hopper)
2. Press the latch button to open the printer swingarm.
3. Remove the print ribbon cartridge.
4. Load a full roll of print ribbon (blue spool) onto the spindle closest to the
cartridge handle until it clicks into place.
5. Place the silver take-up spool on the spindle with the black gear until it clicks
into place.
6. Wind the take-up spool counterclockwise one full turn.
7. Load the cleaning sleeve. Refer to "Replace the Cleaning Sleeve" on page 11.
8. Replace the print ribbon cartridge.
9. Close the printer swingarm (and close the supplies door on the multi-hopper)
and lock the printer.
10
