Entrust CD820 Quick Install Manual

Instant issuance system
Hide thumbs Also See for CD820:
Table of Contents

Advertisement

Quick Links

Download this manual
Quick Install Guide
CD820™ Instant Issuance
System
October 2020
527662-002, Rev H

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CD820 and is the answer not in the manual?

Questions and answers

Related Manuals for Entrust CD820

Summary of Contents for Entrust CD820

  • Page 1 Quick Install Guide CD820™ Instant Issuance System October 2020 527662-002, Rev H...
  • Page 2 CD820 Instant Issuance System WARNING: This product contains chemicals, including lead, known to the State of California to cause cancer, and birth defects or other reproductive harm. Wash hands after handling. WARNING: This product can expose you to chemicals including...

  • Page 3: Select A Location For The Printer

    Refer to the printer’s Installation and Administrator’s Guide found on the Owner’s Library CD for detailed installation instructions. The latest firmware and user documentation for your CD820 printer is available for download at www.entrustdatacard.com. 1. Select a Location for the Printer •...

  • Page 4: Set Up The Printer

    CD820 Instant Issuance System 2. Set Up the Printer a. Remove the printer from its shipping carton. Refer to the following illustration if the printer has the optional multi-hopper.
  • Page 5 Quick Install Guide b. Unlock the printer and open the printer cover. c. If the printer has the optional multi-hopper, unlock the printer and open the printer supplies access door and the multi-hopper cover. Remove the packing material inserted behind the hopper and inside the cover.

  • Page 6: Load Supplies

    CD820 Instant Issuance System 3. Load Supplies Supplies are ordered separately. a. Remove the print ribbon cartridge. b. Load the print ribbon onto the cartridge.
  • Page 7 Quick Install Guide c. Load the cleaning sleeve onto the ribbon cartridge. d. Install the print ribbon cartridge in the printer. e. Close the printer cover. Press down on the cover ridges to make sure that the cover latches properly on both sides.
  • Page 8 CD820 Instant Issuance System Load cards in the hopper. Single Hopper Multi-Hopper g. Close the printer doors and lock the printer.

  • Page 9: Plug In And Power On The Printer

    Quick Install Guide 4. Plug In and Power On the Printer a. Connect the printer power cord to the printer and to the power supply. b. Plug the power supply cord into the power outlet. c. Press the Power button on the front panel to power on the printer.

  • Page 10: Activate The Printer

    CD820 Instant Issuance System 5. Activate the Printer a. If the printer requires activation, call 1-800-328-3996 to obtain an activation code. b. Have the printer’s serial number ready when you call. The serial number is located on the configuration label on the printer swingarm.
  • Page 11 Quick Install Guide c. Enter the activation code. Press until correct digit displays Repeat 6 & 7 for each digit...

  • Page 12: Set A Static Ip Address

    CD820 Instant Issuance System 6. Set a Static IP Address Datacard CardWizard issuance software requires the ® ® printer to have the same IP address at all times. a. Obtain the following information from your system administrator: IP address _________________________...
  • Page 13 Quick Install Guide c. Follow the same process to enter the subnet mask and gateway address.
  • Page 14 CD820 Instant Issuance System 7. Print a Test Card (Optional) Use the printer’s LCD panel to print a test card:...

  • Page 15: Next Steps

    Quick Install Guide 8. Next Steps • Define the printer to CardWizard software. Refer to the CardWizard and Card Printer Setup Guide for information. • Contact your system administrator to set up the rest of the system. • Set up security, including network authorization to the printer.
  • Page 16 Entrust, Sigma and the hexagon design are trademarks, registered trademarks and/ or service marks of the Entrust Corporation in the United States and other countries. Datacard is a registered trademark and service mark of Entrust Corporation in the United States and other countries. All other trademarks are the property of their respective owners.
