2.3.13
USB
EPC-R6410 supports 6 x USB2.0 type A connectors
Pin
15
16
17
18
19
20
21
22
Pin
A1
A2
A3
A4
B1
B2
B3
B4
C1
C2
C3
Description
+5V_USB_P56_B
USB_P6L_N
USB_P6L_P
USBV56_GND
+5V_USB_P56_B
USB_P5L_N
USB_P5L_P
USBV56_GND
Description
+5V_USB_P12_B
USB_P1L_N
USB_P2L_P
USB_12_GND
+5V_USB_P12_B
USB_P2L_N
USB_P2L_P
USB_12_GND
+5V_USB_P34_B
USB_P3L_N
USB_P3L_P
17
