2.3.11
VGA
EPC-R6410 supports VGA; pin definitions below:
Pin
Description
1
VGA_b_R
2
VGA_b_G
3
VGA_b_B
4
NC
5
GND
6
GND
7
GND
8
GND
Pin
Description
9
+5V_CRT
10
GND
11
NC
12
VGA_b_DDC_DAT
13
VGA_b_HSYNC
14
VGA_b_VSYNC
15
VGA_b_DDC_CLK
15
