7
8
9
CN18
Part Number
Footprint
Description
Setting
(1-2)
(2-3)
2.3.4
COM4/COM5/COM2 RS232
EPC-R6410 supports 3 x RS232 with 4wires, as COM2, COM4, COM5. Pins are
defined below:
Pin
1
2
3
4
5
6
7
8
9
EPC-R6410 Android User Manual
NC
NC
NC
COM0 RS232 and debug mode select
1653003101
HD_3x1P_79_D
PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-13 WS
function
COM0 is debug port
(default)
COM0 is RS232 COM port
Description
NC
COM2_RX
COM2_TX
NC
GND
NC
COM2_RTS
COM2_CTS
NC
COM port
8
