- Page 1 EWM-W180H01E User Manual...
- Page 2 Applicability Type AIW PN Description WPET- 802.11ac/b/g/n half-size mini-PCIe solution based on EWM-W180H01E 239ACN(BT) RTL8822CU...
-
Page 3: Revision History
Revision History Version Owner Date Description V1.0 Joejohn.Chen 2023-05-19 First issue 1. Model name typo correction V1.1 Joejohn.Chen 2023 -11-02 2. Height dimension correction 3. Add information about label and packing V1.2 Joejohn.Chen 2023-12-18 Dimension correction on 2D drawing 1. Fix operating temperature V1.3 Joejohn.Chen 2024-03-07... -
Page 4: Product Introduction
1 Product Introduction Item Description IEEE 802.11ac/a/b/g/n (2T2R) Standard Bluetooth V5.0, 4.2, V4.1, V4.0LE, V3.0, V2.1+EDR Chipset solution Realtek RTL8822CU 802.11b: 11Mbps, 5.5, 2, 1Mbps 802.11a/g: 54, 48, 36, 24, 18, 12, 9, 6Mbps 802.11n: MCS0~15 for HT20MHz & HT40MHz Data Rate 802.11ac: MCS0~8 for HT20MHz... - Page 5 Wi-Fi: 802.11b: DSSS (DBPSK, DQPSK, CCK) Modulation 802.11g: OFDM (BPSK, QPSK, 16-QAM, 64-QAM) 802.11n: OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
- Page 6 Item Description 802.11a: OFDM (BPSK, QPSK, 16-QAM, 64-QAM) 802.11ac: OFDM (BPSK, QPSK, 16-QAM, 64-QAM, 256- QAM) Modulation Header: GFSK Payload 2M: π/4-DQPSK Payload 3M: 8-DPSK TX mode: 600 mA (Max) Power Consumption RX mode: 350 mA (Max) Operating Voltage DC 3.3V Operating -20°C~70°C Temperature Range...
- Page 7 Note: 1. For Radio stream with diversity or MIMO design, all RF connectors on the module must be fitting antennas in order to guarantee the module performance. 2. The frequency range is subject to local regulations. 3. The storing condition is only for product functionality, no included for parts appearance.
- Page 8 2 Output Power & Sensitivity 2.1 Wi-Fi 802.11b Data Rate Tx ± 2dBm Rx Sensitivity ≦-76dBm 11Mbps 17dBm 802.11g Data Rate Tx ± 2dBm Rx Sensitivity ≦-65dBm 54Mbps 16dBm 802.11n / 2.4GHz Tx ± 2dBm Tx ± 2dBm Data Rate Rx Sensitivity (1TX) (2TX)
- Page 9 802.11ac Tx ± 2dBm Tx ± 2dBm Data Rate Rx Sensitivity (1TX) (2TX) VHT80 ≦-51dBm MCS9 11dBm 14dBm 2.2 Bluetooth Bluetooth Data Rate Tx ± 2dBm (Class 1 Device) Rx Sensitivity 0≦ Output Power ≦3.5dBm <0.1% BR, BER at -80dBm 3Mbps...
-
Page 10: Hardware Specification
3 Hardware Specification 3.1 Mechanical Dimension Dimension (L x W x H): 29.9 mm (Tolerance:±0.3mm) x 26.6 mm (Tolerance:±0.3mm) x 3 mm (Tolerance:±0.3mm) Figure 3-1: Hardware Dimension... - Page 11 3.2 MHF1 connector spec Figure 3-2: MHF4 connector spec...
-
Page 12: Block Diagram
3.3 Block Diagram Figure 3-3: Block Diagram... -
Page 13: Pin Assignment
3.4 Pin Assignment The following section illustrate signal pin-outs for the module connector. l Top Side Pin Name Type Description WAKE# No Connection USB_D+ No Connection USB_D- No Connection CLKREQ0# No Connection Ground connections REFCLK- No Connection REFCLK+ No Connection Ground connections UIM_IC_DM No Connection... - Page 14 Pin Name Type Description +3.3Vaux No connections +3.3Vaux No connections Ground connections ANTCTRL2 No connections ANTCTRL3 No connections Reserved No connections W_DISABLE2# No connections Table 2-1 Top side pin assignment...
-
Page 15: Bottom Side
l Bottom Side Pin Name Type Description +3.3Vaux VDD system power supply input 3.3V Ground connections 1.5V/COEX3 No Connection UIM_PWR No Connection UIM_DATA No Connection UIM_CLK No Connection UIM_RESET No Connection UIM_SPU No Connection Ground connections W_DISABLE1# No Connection PERST# No Connection +3.3Vaux No Connection... - Page 16 Pin Name Type Description Open drain, active low signals. These signals are used to allow the PCI Express LED_WLAN# Mini Card add-in card to provide status indicators via LED devices that will be provided by the system. LED_WPAN# No Connection +1.5V/ANTCTRL1 No Connection Ground connections...
- Page 17 3.5 Product Label Information...
- Page 18 3.6 Packing and Carton Information Below information is only for standard package.
