- Page 1 EWM-W192 series User Manual...
- Page 2 Applicability Type AIW PN Description IEEE 802.11ac (2.4GHz+5GHz) + BT 5.0, 2T2R, M.2 EWM-W192K Intel AC9260 2230 Key A/E with antennas and cables...
-
Page 3: Revision History
Revision History Version Date Description Official version V1.0 2023-06-09... - Page 4 1 Foreword 1.1 Introduction The document describes how to install driver of EWM-W192K series product in Windows 10.
- Page 5 Download the driver from below link. Please check with your sales team if you require drivers for other windows driver and Linux. Windows 10 driver for EWM-W192 series Step 2 - Install Your Driver Once you have downloaded your new driver, you'll need to install it. In Windows, use a built-in utility called Device Manager, which allows you to see all of the devices recognized by your system, and the drivers associated with them.
- Page 6 3. Click the Update Driver button and follow the instructions. In most cases, you will need to reboot your computer for the driver update to take effect. Once you execute the exe. file from the driver folder, please just press the next button.
- Page 7 Please agree the terms and conditions requested by Intel and press Install button.
- Page 8 Please wait few seconds for the driver installation.
- Page 9 After driver installation, you should see the Intel AC9260 device in the device manager and be able to connect with AP in your space. Notice: To avoid any trouble, please follow the instructions provided by Advantech and do not use EWM-W192 series in other ways without discussion with Advantech’s team.
-
Page 10: Explosive Device Proximity Warning
INFORMATION FOR THE USER Safety Notices (Based on Intel’s Safety regulation &limitation) USA FCC Radio Frequency Exposure The FCC with its action in ET Docket 96-8 has adopted a safety standard for human exposure to radio frequency (RF) electromagnetic energy emitted by FCC certified equipment. The wireless adapter meets the Human Exposure requirements found in FCC Part 2, 15C, 15E along with guidance from KDB 447498, KDB 248227 and KDB 616217. - Page 11 Antenna Warnings: Warning: The wireless adapter is not designed for use with high-gain directional antennas. Use On Aircraft Caution Caution: Regulations of commercial airline operators may prohibit airborne operation of certain electronic devices equipped with radio-frequency wireless devices (wireless adapters) because their signals could interfere with critical aircraft instruments.
-
Page 12: Regulatory Information
The Wireless Adapter and Your Health The wireless adapter, like other radio devices, emits radio frequency electromagnetic energy. The level of energy emitted by the wireless adapter, however, is less than the electromagnetic energy emitted by other wireless devices such as mobile phones. The wireless adapter operates within the guidelines found in radio frequency safety standards and recommendations. - Page 13 antenna that is built into the computer. Details of the authorized configurations can be found at http://www.fcc.gov/oet/ea/ by entering the FCC ID number on the device. Class B Device Interference Statement This wireless adapter has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
-
Page 14: Label Of The End Product
The end user has to also be informed that any changes or modifications not expressly approved by the manufacturer could void the user's authority to operate this equipment. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 15 3.04 dBi for 5725~5850 MHz 2.57 dBi for 5150~5250 MHz 2.57 dBi for 5250~5350 MHz RFPCA351455EMLB901 (Aux) 2.37 dBi for 5470~5725 MHz 3.40 dBi for 5725~5850 MHz Note: The antenna connector is Reverse IPEX4 type. Innovation, Science and Economic Development Canada (ISED) Notices This device complies with Canada licence-exempt RSS standard(s).
- Page 16 Avertissement: Le guide d’utilisation des dispositifs pour réseaux locaux doit inclure des instructions précises sur les restrictions susmentionnées, notamment : (i) les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux;...
-
Page 17: Important Note
Tant que les 2 conditions ci-dessus sont remplies, des essais supplémentaires sur l'émetteur ne seront pas nécessaires. Toutefois, l'intégrateur OEM est toujours responsable des essais sur son produit final pour toutes exigences de conformité supplémentaires requis pour ce module installé. IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or colocation with another transmitter), then the Canada authorization is no longer considered valid and... - Page 18 étiqueté dans un endroit visible avec l'inscription suivante: "Contient des IC: 9404A-EWMW192K” Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warning as show in this manual.
- Page 19 3.24 3.47 3.73 4.77 4.77 MIMO *All antenna gains include cable loss. Antenna List - 2.4G Manufacturer Part No. Antenna Peak Gain Type 1 INPAQ RFPCA351746EMLB901 (Main) 2.41 dBi for 2400 MHz RFPCA351455EMLB901 (Aux) 2.60 dBi for 2400 MHz Antenna List - 5G No.
- Page 20 It must be installed into a compliant host device meeting the requirement of UL/EN/IEC 60950-1 2nd edition including the general provisions of enclosure design 1.6.2 and specifically paragraph 1.2.6.2 (Fire Enclosure). The device shall be supplied by a SELV source when installed in the end-use equipment.
