2.3.5
CAN
EPC-R6410 supports 1xCAN; pins defined below:
Table 2.4: CAN
Pin
1
2
3
4
5
6
7
8
9
2.3.6
GPIO
EPC-R6410 supports 8 x GPIO via a DB9 connector. Pins are defined below:
Table 2.5: GPIO
Pin
1
2
3
4
5
6
7
8
9
EPC-R6410 Android User Manual
Description
NC
CAN_D+
NC
NC
GND
NC
CAN_D-
NC
NC
Description
GPIO0
GPIO1
GPIO2
GPIO3
GPIO4
GPIO5
GPIO6
+V_GPIO
GND
10
