4.4.5
Build android OTA package
1.
Open a terminal console and change directory to BSP scripts folder
2.
Perform the following command:
root@PcName:~# ./mk_otapackage.sh <product name>
where <product name> is:
• EPC-R6410 for EPC-R6410 board
3.
Then you can get the android kernel image file named update.zip under image
folder
4.5
Debug Console
Connect the 9-pin D-SUB of debug console cable with the host computer serial port
using a serial port terminal application (like minicom, putty or teraterm) then config
serial port as 115200 8N1.
Then plug in the 4-pin connector debug console cable into EPC-R6410's debug port
(also known as /dev/ttymxc0 in Android)
4.6
Boot up from SD card or eMMC
EPC-R6410 supports boot from SD card or onboard flash. This section will guide you
how to build an image for EPC-R6410 Android system boot media.
4.6.1
The storages devices name as following:
Device
SD card
eMMC
4.6.2
Create a bootable SD card
You are able to find the pre-built image from Advantech website. Please follow the
steps below to create an SD card for boot up.
1.
Copy "EPC-R6410AIVxxxx_yyyy-mm-dd.tar.gz" package to your /root/.
2.
Open "Terminal" on Ubuntu 14.04 LTS..
3.
$sudo su (Change to "root" authority)
4.
Input your password.
5.
root@PcName:~# cd /root/
6.
root@PcName:~# tar xzvf EPC-R6410AIVxxxx_yyyy-mm-dd.tar.gz (Unzip files)
7.
Insert one SD card into your development computer
8.
Check the SD card location, like /dev/sdb
9.
root@PcName:~# cd ./ EPC-R6410AIVxxxx_yyyy-mm-dd/scripts
10.
root@PcName:~#./mksd-android.sh /dev/sdb
Then insert the SD card to EPC-R6410 and power up, it should boot up with an
Android environment.
Name
/dev/block/mmcblk1
/dev/block/mmcblk0
37
EPC-R6410 Android User Manual
