- Page 1 User Manual EKI-1526NL-CS EKI-1528NL-CS 8/16 port RS-232 Console Server (Rackmount)
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable.
- Page 3 This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information.
- Page 4 être important pour constituer un risque d'électrocution. This symbol is intended to alert the user to the potential presence of a hot surface. Ce symbole est prévu pour alerter l'utilisateur de la présence potentielle d'une surface chaude. EKI-1526NL-CS | 1528NL-CS User Manual...
- Page 5 REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS. Warning! This equipment is not suitable for use in locations where children are likely to be present. EKI-1526NL-CS | 1528NL-CS User Manual...
- Page 6 à la terre. La prise de courant doit être proche de l'appareil et facilement accessible. Vous ne pouvez couper l'alimentation de l'appareil qu'en débranchant le cordon d'alimentation dès la prise de courant. EKI-1526NL-CS | 1528NL-CS User Manual...
- Page 7 Connectez et déconnectez les câbles comme indiqué dans le tableau suivant lorsque vous installez, déplacez ou ouvrez des capots sur ce produit ou sur des appareils connectés. EKI-1526NL-CS | 1528NL-CS User Manual...
- Page 8 Notice About this manual The illustrations as shown in this manual are for instructional purposes only. EKI-1526NL-CS | 1528NL-CS are suitable for installation in Information Technology Rooms in accordance with Article 645 of the National Electrical Code and NFPA 75. The device can only be used in a fixed location such as a telecommunication centre, a dedicated computer room.
- Page 9 Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –...
-
Page 10: Table Of Contents
USDG TCP Client Mode ............. 37 4.3.2 USDG Data TCP Server mode ........... 38 4.3.3 USDG UDP Server/Client mode ..........39 USDG Control mode ................40 4.4.1 Hangup Character............... 40 4.4.2 Guard Time ................. 40 RFC2217 Mode..................41 EKI-1526NL-CS | 1528NL-CS User Manual... - Page 11 Ping..................... 84 7.9.2 Reboot ..................85 7.10 Management ................... 85 7.10.1 Log File ..................85 7.10.2 Change Password ..............85 7.10.3 Secure access IP................ 86 7.10.4 Export Device Settings ............... 86 7.10.5 Import Device Settings..............87 EKI-1526NL-CS | 1528NL-CS User Manual...
- Page 12 8.4.12 service..................97 8.4.13 mrfc2217 ..................97 8.4.14 apply ................... 97 8.4.15 exit ....................97 8.4.16 help ..................... 97 8.4.17 reboot..................97 Chapter TCP and UDP Port Numbers.....98 List of Known TCP and UDP Port Numbers..........99 EKI-1526NL-CS | 1528NL-CS User Manual...
- Page 13 Figure 5.13 Service > Local User Management ................51 Figure 5.14 Service > OpenVPN Client Setting ................52 Figure 5.15 Service > OpenVPN Client Sample Configuration............54 Figure 5.16 User Log Diagram ....................... 55 xiii EKI-1526NL-CS | 1528NL-CS User Manual...
- Page 14 Figure 8.3 Telnet Connection Console ..................90 Figure 8.4 Creating a Serial Connection ..................91 Figure 8.5 Creating a Serial Connection ..................91 Figure 8.6 COM Port Settings ...................... 92 Figure 8.7 Connection success ....................93 EKI-1526NL-CS | 1528NL-CS User Manual...
-
Page 15: Chapter 1 Overview
Chapter Overview... -
Page 16: Introduction
1528NL-CS. The Advantech EKI-1500 series of console servers consist of fast and cost- effective device servers between serial RS-232 and Ethernet interfaces. The two Ethernet ports allow the EKI-1526NL-CS | 1528NL-CS to establish two separate Ethernet connections to two Ethernet domains or switches in the same domain. -
Page 17: Device Specifications
50 bps ~ 921.6 kbps, any baud rate setting 16 ports up to 230.4 kbps simultaneously Protection Built-in 15 KV ESD for all signals Power Power Consumption Power Input 100 ~ 240 V , 50 ~ 60 Hz EKI-1526NL-CS | 1528NL-CS User Manual... - Page 18 TCP/UDP client (event handling) mode Pair connection (peer to peer) mode RFC2217 mode Configuration Windows utility, Telnet console, web browser, serial console Management SNMP MIB-II Regulatory CE, FCC Part 15 Subpart B (Class A) Approvals EKI-1526NL-CS | 1528NL-CS User Manual...
-
Page 19: Chapter 2 Getting Started
Chapter Getting Started... -
Page 20: Hardware Overview
Hardware Overview 2.1.1 Front View The following view shows the EKI-1526NL-CS. EKI-1526NL-CS Link/Active Reset Serial Status Console Speed Figure 2.1 Front View No. Item Description Reset button Button allows for system soft reset (3 sec.). Serial port DB9 pin out, console port (female). -
Page 21: Led Indicators
Serial communication RJ45 ports x 8 ETH port RJ45 ports x 2 Ground terminal Screw terminal used to ground chassis. 2.1.3 LED Indicators The following view shows the EKI-1526NL-CS. Link/Active LAN 1 Serial Status Speed Figure 2.5 System LED Panel No. -
Page 22: Figure 2.6 System Led Panel
AMBER The device server has been located by utility’s location function BLINKING System is ready (1cycle/sec.) System is powered off Speed AMBER 1000 Mbps speed 10/100 Mbps speed AMBER Data being transmitted No data transmitted EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 23: Dimensions
2.1.4 Dimensions The following view shows the EKI-1526NL-CS. 0.34 8.65 17.24 Unit: Figure 2.7 EKI-1526NL-CS Dimensions EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 24: Figure 2.8 Eki-1528Nl-Cs Dimensions
The following view shows the EKI-1528NL-CS. 0.34 8.65 17.24 Unit: mm [Inch] Figure 2.8 EKI-1528NL-CS Dimensions EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 25: Connecting Hardware
Align the product with the posts on the rack cabinet. Secure the product with screws. Re set PW R Lin k/A ctiv e Co nso Sta tus Ser ial 14 15 EK I-1 52 6N L- CS Figure 2.10 Installing the Product EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 26: Serial Connection
EKI-1526NL-CS | 1528NL-CS Series provides 8/16 ports RJ45 phone jack connectors. The RS-232 pin assignments are as follows: Figure 2.11 RJ45 Pin Assignment RS-232 EKI-1526NL-CS | 1528NL-CS provides one RJ45 phone jack connector cable for serial communication. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 27: Power Connection
Attention! Risque d'explosion si la batterie est disposée dans un environnement très exposé au feu ou un environnement chaud ou si elle est endommagée mécaniquement – y compris le bossellement, l’écrasement et la perforation du boîtier de pile. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 28: Figure 2.12 Connecting Ac Power
The following is only available for EKI-1526NL-CS | 1528NL-CS series. Connect the EKI-1526NL-CS | 1528NL-CS series power line with its AC connector. If the power is properly supplied, you can turn on the power switch and the PWR LED lights green. -
Page 29: Chapter 3 Utility Configuration
Chapter Utility Configuration... -
Page 30: Configuration Utility Overview
Advantech Console Server Configuration Utility is an excellent console server management tool. You can connect and configure the local and remote Advantech serial console servers easily. The utility provides access to the following functions: Configure the network settings (you can set the IP address, Gateway address, ... -
Page 31: Figure 3.2 Installshield Wizard 2 Of 4
Figure 3.2 InstallShield Wizard 2 of 4 The InstallShield continues and a status screen displays. The default installation path is C:\Program Files\EKI Device Configuration Utility. Figure 3.3 InstallShield Wizard 3 of 4 EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 32: Figure 3.4 Installshield Wizard 4 Of 4
Once the installation of the package is finished a Configuration Utility Setup screen displays. Click Finish to conclude the process and exit the InstallShield Wizard. Figure 3.4 InstallShield Wizard 4 of 4 EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 33: Menu Bar
Menu Bar You can open the Advantech EKI Device Configuration Utility from the Windows Start Menu by clicking Start > All Programs > EKI Device Configuration Utility > Advantech EKI Device Configuration Utility. The Configuration Utility displays as follows. For the purposes of this manual, the user interface is separated into six sections. -
Page 34: Quick Tool Bar
Quick Tool Bar The Advantech EKI Device Configuration Utility makes use of a Quick Tool Bar menu to allow quick access to the management functions. See the following figure for further information. Figure 3.6 Quick Tool Bar Overview Icon Item... -
Page 35: Utility Settings
NOTE: A restart is required for the settings to take effect. Click OK to save and exit the Utility Settings menu. Cancel Click Cancel to discard the changes. Click Apply to save the main form settings. Apply EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 36: Figure 3.8 View > Settings > Device Manager
Check the check box to enable or disable answer automatically for unsigned hardware unsigned hardware installation. installation Click OK to save and exit the utility setting. Click Cancel to discard the changes. Cancel Click Apply to save the utility setting. Apply EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 37: Discovering Your Console Server
3.4.2.1 Auto Searching Advantech EKI Device Configuration Utility 1.67 or higher will automatically search all the EKI-15xx series serial console servers on the network and show them on the Server List Panel of the utility. The utility provides an auto-search function to show your device (s) by simply executing the configuration utility program from the Start Menu. -
Page 38: Figure 3.10 Selecting A Group
IP. Figure 3.10 Selecting a Group Click on the “+” before the device name, and the utility will expand the interfaces on this console server. Figure 3.11 Selecting a Device EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 39: Network Settings
BOOTP / AutoIP: mode to automatically assign an IP address through the configuration server DHCP/BOOTP/AutoIP: mode to automatically assign an IP address using a Bootstrap Protocol or DHCP server. The server is set with the following default IP configuration: 10.0.0.1 (Eth1) 10.0.0.2 (Eth2) EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 40: Figure 3.13 Network Settings Overview
“Apply” button in order to make these settings effective on the Serial Console Server. Click Reboot to reboot the serial console server. Any configuration changes you have made since the last time you saved will be lost. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 41: Figure 3.14 Reset Device
To reset the device: Right-click a desired device to display the settings menu. Select Reset Device. Figure 3.14 Reset Device EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 42: Administrator Settings
Select Locate from the menu. Figure 3.15 Locate the Console Server The unit’s Status LED will turn solid amber, and the buzzer will make a beep sound until you click Stop Locate. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 43: Securing The Serial Console Server
Right-click a desired device to display the settings menu. Select Lock Device. Figure 3.16 Lock the Serial Console Server Enter a password. Retype the password entry to confirm the profile password. Figure 3.17 Enter a Password EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 44: Figure 3.18 Reset Device
Right-click a desired device to display the settings menu. Select Reset Device to restart the serial console server and store your setting password into the memory. Figure 3.18 Reset Device EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 45: Restore To Factory Default Settings
Power off the serial console server within ten seconds. After reconnecting the power, all settings will be reset to the factory default. If the power supply remains connected for more than ten seconds, the serial console server will not be changed. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 46: Resetting The Device
EKI console servers. 3.5.6 Auto Mapping See “Auto Mapping” on page 58 for further details. 3.5.7 Manual Mapping See “Manual Mapping” on page 60 for further details. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 47: Update Firmware
3.5.8 Update Firmware Advantech continually upgrades its firmware to keep up with the ever-expanding world of computing. You can use the update firmware function in the utility to carry upgrade procedure. Please access Advantech’s website: http:// www.advantech.com to download the latest version of the firmware. Before updating the firmware, make sure that your host’s network domain is as same as the serial... -
Page 48: Chapter 4 Selecting An Operating Mode
Chapter Selecting An Operating Mode... -
Page 49: Overview
PC. The Advantech redirector can create up to 255 virtual COM ports. Application on the host can open virtual COM port to access the console servers at the same time. The redirector will handle each active virtual COM port as a separate TCP connection to Advantech console servers. -
Page 50: Normal Mode
Every host can transmit data to the same serial port, and the EKI-1526NL-CS | 1528NL-CS Series will also transmit data to every hosts. When the multiple hosts transmit data to the same serial port at the same time, the received data from Ethernet and the outputs of serial port are mixed. -
Page 51: Usdg Data Mode
USDG Data Mode The EKI-1526NL-CS | 1528NL-CS Series can function either as Data server or Data client. Both operations support TCP and UDP protocols. The Series allows you to treat your serial devices as if they were networking devices. You can issue commands or transmit data from serial devices, connected to a EKI-1526NL-CS | 1528NL-CS Series device, to any devices that are connected to the Internet. -
Page 52: Usdg Data Tcp Server Mode
EKI console server from a single or multiple hosts. However a multi-host connection simultaneously transmits the data from a single serial port. EKI-1526 12 13 14 15 Figure 4.5 USDG TCP Server Mode EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 53: Usdg Udp Server/Client Mode
The default TCP/UDP port of the EKI-1526NL-CS | 1528NL-CS Port1 is 5300, Port2 is 5301, etc. Users can adjust them according to preference or application. Each port has its own data listen port to accept the connection requests of other network device. -
Page 54: Usdg Control Mode
TCP connection to the networking device (192.0.55.22). The TCP port is 5201. ATA <CR> Answering an incoming call +++<CR> Returns the user to the command prompt when entered from the serial port during a remote host connection. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 55: Rfc2217 Mode
RFC2217 defines general COM port control options based on the Telnet protocol. Third party drivers supporting RFC2217 are widely available on the Internet and can be used to implement virtual COM mapping to the serial port of your device. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 56: Ssh Console Mode
Chapter SSH Console Mode... -
Page 57: Introduction
Port destination as configured in the Listen Port setting. To connect the EKI, the SSH client must also be configured to use TCP port 5600. Save Click Save to save the values. Figure 5.2 SSH Client Destination Port Setting EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 58: Ssh Console Settings
The SSH Console Setting function allows for the set up of the system wide configurations related to the SSH console service. To access this page, navigate to Service and click SSH Console Setting. The LDAP Setting page displays. Figure 5.4 Service > SSH Console Setting EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 59: Radius Setting
Displays the DN of the directory, which stores users with read-only permission, see the following example: If set to ou=r,ou=port1,ou=eki-1,dc=advantech,dc=com, and LDAP key is cn, and a SSH client logs in to this serial console service as someone the DN used to check against the LDAP will be cn=someone,ou=r,ou=port1,ou=eki-1,dc=advantech,dc=com. -
Page 60: Figure 5.6 Service > Radius Setting, Access Setting
Read-Write Header Displays the user name prefix label of the RADIUS server for validating read-write permissions. Config Header Displays the user name prefix label of the RADIUS server for validating basic serial port configuration permission. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 61: Local User Management
Click Save to save the values. 5.2.5.1 Adding a Local User To add a local user, see the following: To access this page, navigate to Service and click Local User Management. The Local User Management page displays. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 62: Figure 5.8 Service > Local User Management
None: No read/write permission to the serial port • Read-Only: Read-Only permission to the serial port. • Read-Write: Read-Write permission to the serial port. • Config: Permission to change basic settings to the serial port. Click Save to complete the process. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 63: Figure 5.9 Adding A Local User
Figure 5.10 Completed Local User Listing 5.2.5.2 Editing a Local User To add a local user, see the following: To access this page, navigate to Service and click Local User Management. The Local User Management page displays. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 64: Figure 5.11 Service > Local User Management
None: No read/write permission to the serial port • Read-Only: Read-Only permission to the serial port. • Read-Write: Read-Write permission to the serial port. • Config: Permission to change basic settings to the serial port. Click Save to complete the process. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 65: Figure 5.12 Editing A Local User
To access this page, navigate to Service and click Local User Management. The Local User Management page displays. Figure 5.13 Service > Local User Management From the Access Setting pane, select a listing and click Delete to remove the listing. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 66: Openvpn Client Setting
Click to enable or disable (default) the feature to allow the OpenVPN Authentication server to query the user for a password to pass on to the server over a secure TLS channel. Username Enter the user name authorized to access the OpenVPN server account. EKI-1526NL-CS | 1528NL-CS User Manual... - Page 67 The following is a sample of an OpenVPN Client configuration setting under a united format (GitHub) for an .ovpn file. For demonstration purposes Profile has been selected under Method and the .ovpn file contents are listed. EKI-1526NL-CS | 1528NL-CS User Manual...
-
Page 68: Figure 5.15 Service > Openvpn Client Sample Configuration
Figure 5.15 Service > OpenVPN Client Sample Configuration EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 69: Managing The Authentication Of Ssh Console Users
Figure 5.16 User Log Diagram 5.3.1 Timeout SSH console mode keeps the authentication timestamp of each and every logged in user. Once an authentication has pass a certain amount of time, EKI will update with EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 70: Rapid (Timeout)
1 and user 3 are switched into the rapid update period, because user 2's permission has changed. After discovering user 1's new permission, user 2 and user 3, again, are both switched into the rapid update period. Figure 5.18 Rapid Timeout Diagram EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 71: Setting Up Virtual Com Redirector
Chapter Setting Up Virtual COM Redirector... -
Page 72: Setting Com Redirector
Setting COM Redirector Advantech COM port mapping software is a serial COM port redirector that creates virtual COM ports and provides access to serial devices connected to an Advantech console servers. Your serial device applications can communicate with serial devices connected to the Advantech console servers without software changes. -
Page 73: Figure 6.2 Selecting Auto Mapping
Once the mapping function is initialized, a successful mapping process results in the virtual mapping of the designated physical serial port and VCOM PC port. See the following figure. Figure 6.4 Viewing VCOM Mapping Results EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 74: Manual Mapping
Manual Mapping On your desktop, navigate to Start > All Programs > EKI Device Configuration Utility and click Advantech EKI Device Configuration Utility to open the utility. Under Serial Device Servers, locate your server and click the icon to expand the listing. -
Page 75: Configuration Wizard
Configuration Wizard On your desktop, navigate to Start > All Programs > EKI Device Configuration Utility and click Advantech EKI Device Configuration Utility to open the utility. Under Serial Device Servers, locate your server and click the icon to expand the listing. -
Page 76: Confirming Virtual Com Settings
Confirming Virtual COM Settings On your desktop, navigate to Start > All Programs > EKI Device Configuration Utility and click Advantech EKI Device Configuration Utility to open the utility. Locate Serial Ports menu in the menu pane and click on the Expand icon next to Virtual COM Ports to view a list of the mapped ports. -
Page 77: Figure 6.10 System Port Vcom Mapping Configuration
The newly mapped VCOM port is listed under the same mapped settings used in the previous steps. The settings correspond to the VCOM port configuration on the EKI device, see the following figure. Figure 6.11 Verifying VCOM Mapping Configuration EKI-1526NL-CS | 1528NL-CS User Manual... - Page 78 If the settings do not correspond, the VCOM mapping is not correct. See “Virtual COM Port Mapping” on page 58 to re-map the VCOM ports. EKI-1526NL-CS | 1528NL-CS User Manual...
-
Page 79: Removing Vcom Ports
Removing VCOM Ports On your desktop, navigate to Start > All Programs > EKI Device Configuration Utility and click Advantech EKI Device Configuration Utility to open the utility. Under Serial Ports, click the expand icon on Virtual COM Ports to view the configured port list. -
Page 80: Importing Vcom Mapping
To import VCOM mapping: On your desktop, navigate to Start > All Programs > EKI Device Configuration Utility and click Advantech EKI Device Configuration Utility to open the utility. Under Serial Device Servers, locate your server and click the icon to expand the listing. -
Page 81: Web Configuration
Chapter Web Configuration... -
Page 82: Overview
Overview EKI-1526NL-CS | 1528NL-CS console servers can be configured through a web interface. By using a standard web browser, the same procedure as with the Windows configuration utility can be used. In the browser’s address field, enter the IP Address of your EKI-1526NL-CS | 1528NL-CS console server.s The default IP setting is 10.0.0.1, but you should use the IP which you have previously assigned for... -
Page 83: Accessing The Web Page Via Web Browser
Click Enabled or Disabled to set remote access through the Telnet Service function. VCOM Ignore Device SNMP Click Enabled or Disabled to define the SNMP daemon. Local Time Click Modify to set local date and time of the system. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 84: Ethernet Configuration
10.0.0.1 (Eth1) & (0.0.0.2 (Eth2). Subnet Mask Enter a value to specify the IP subnet mask for the interface. The default is 255.0.0.0. Default Gateway Enter a value to specify the default gateway for the interface. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 85: Port Configuration
Click the drop-down menu to select the parity: None, Odd, Even, Mark or Space. Data Bits Click the drop-down menu to select the data bits: 5, 6, 7, or 8. Stop Bits Click the drop-down menu to select the stop bits: 1, 1.5 or 2. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 86: Operation
Host Idle Timeout (s) Enter a value to define the host idle timeout period. Response Timeout Enter a value to define the response timeout period. (ms) Frame Break (ms) Enter a value to specify the frame break time. Pack conditions (Pack sent immediately when reach 1024 Bytes) EKI-1526NL-CS | 1528NL-CS User Manual... - Page 87 Enter a value to identify the channel for remote initiating connections. Host Idle Timeout (s) Enter a value to define the host idle timeout period. Save Click Save to save the values and update the screen. EKI-1526NL-CS | 1528NL-CS User Manual...
-
Page 88: Advanced
Click the option to enter the value to queue data to become a packet. Size Port Timeout Settings determine the time period that received data from serial port is postponed. Click the option to enter the value to define the timeout period. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 89: Monitor
The Monitor function provides a method to monitor the console server’s status (operation mode, baud rate, data bits, stop bits, parity and RTS/XON/DTR). Monitoring information is divided into three main message types: Setting/Statistic/ Connected IP. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 90: Setting
Display the current parity of the selected port. RTS/CTS Display the current RTS/CTS status of the selected port. XON/XOFF Display the current XON/OFF status of the selected port. DTR/DSR Display the current DTR/DSR status of the selected port. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 91: Statistic
Display the current CTS status of the selected port. Display the current DTR status of the selected port. Display the current DSR status of the selected port. Display the current DCD status of the selected port. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 92: Connected Ip
The displayed attributes are not configurable in this menu, and are for information purposes only. Item Description Connected IP Displays the IP designation for the device. IP Address Displays the current connected IP address of the selected port. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 93: Alert
From Email address This is the e-mail address from which automatic e-mail warnings will be sent. Email addresses 1-4 This is the e-mail address or addresses to which the automatic e-mail warnings will be sent. SNMP Trap Server EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 94: Event
(Mail, SNMP, or log file) to record or send event messages. System event notification is available for cold start, warm start, authentication failure, IP address/Password change, serial DCD/DSR port change and Ethernet link down information. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 95: Figure 7.11 Alarm > Event
To access this page, click Alarm > Event. Figure 7.11 Alarm > Event The following table describes the items in the previous figure. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 96: Syslogd
Syslogd Setting Users can enable the syslogd function to record historical events or messages locally or on a remote syslog server. To access this page, click Syslogd > Syslogd Setting. Figure 7.12 Syslogd > Syslogd Setting EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 97: Syslogd Message
Click Save to save the values and update the screen. Save 7.8.2 Syslogd Message After enabling the syslogd function, users can check the history in the syslogd message page. To access this page, click Syslogd > Syslogd Message. Figure 7.13 Syslogd > Syslogd Message EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 98: Tools
Enter the number of echo requests to send. The default value is 4. The value ranges from 1 to 5. The count entered is not retained across a power cycle. Run ping Display the ping reply format. Click Ping to start ping remote station. Ping EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 99: Reboot
Click Save to save the values and update the screen. 7.10.2 Change Password The Change Password function allows you to easily update your current password from a single menu. To access this page, click Management > Change Password. Figure 7.16 Management > Change Password EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 100: Secure Access Ip
Click Save to save the values and update the screen. 7.10.4 Export Device Settings Export the server configuration settings to a .conf file. To access this page, click Management > Export. Click Export to export the console server settings. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 101: Import Device Settings
To access this page, click Management > Import. Figure 7.18 System The following table describes the items in the previous figure. Item Description Choose File Click Choose File to select the configuration file. Submit Click Submit to backup the settings. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 102: Chapter 8 Telnet
Chapter Telnet... -
Page 103: Overview
Telix and other related terminal software. Telnet Console 8.2.1 Create a new connection You can create a new Telnet connection and assign a connection name for the console configuration. Figure 8.1 Creating a Telnet Connection EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 104: Input The Ip Address
Input the IP address Confirm that the Telnet console configuration works ok. Be sure that your host PC Ethernet network IP domain is as same as the EKI-1526NL-CS | 1528NL-CS device server, and the Telnet TCP port number is “23”. -
Page 105: Serial Console
8.3.1 Connecting the cable You can connect to the EKI-1526NL-CS | 1528NL-CS console server’s console port with a RS-232 DB9 M-type communication cable, with the other end connecting to the host’s serial port. Make sure the connection is OK and then run the Hyper Terminal Program on your host. -
Page 106: Com Port Settings
8.3.3 COM Port Settings To connect the EKI-1526NL-CS | 1528NL-CS device server for console configuration, the port setting should match the EKI-1526NL-CS | 1528NL-CS device sever default settings. Figure 8.6 COM Port Settings Console configuration default Settings: Baud rate: 38400 ... -
Page 107: Connection Success
Write settings and reboot the system immediately. 8.4.1 system Usage: system Show current device status and informations. Usage: system name [Maximum length 31 bytes] Set current device name. Usage: system desc [Maximum length 127 bytes] Set current device description. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 108: Port
Set port Writed size of FIFO, null for disable. Usage: portadv [nn|all] rts [] Set port RTS status. – value 0 :None Setting. – value 1 :Setting power on. – value 2 :Setting accept on. – value 4 :Setting transmission on. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 109: Mvcom
Usage: mdata [nn|all] respto [] framebk [] Set response timeout(ms) and frame break(ms). Usage: mdata [nn|all] bysize [] bytime [] bychar [NULL|] bychartimeout [ON|OFF] Set datapackage as size(bytes) or time(ms) or character(HEX) and charactertimeout. – value 0 : None Setting. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 110: Net
Usage: alarm event mail [cstart] [wstart] [auth] [ip] [passwd] [eth1] [eth2] Set current mail event configuration. Usage: alarm event trap [cstart] [wstart] [auth] [eth1] [eth2] Set current trap event configuration. Usage: alarm port [1|2|..] dcd [none|mail|trap|all] dsr [none|mail|trap|all] Set current port alarm configuration. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 111: Monitor
Save the settings to flash and reboot right now. 8.4.15 exit Usage: exit Terminate shell session 8.4.16 help Usage: help [cmd] Display help information of command cmd 8.4.17 reboot Usage: reboot Write settings and reboot the system immediately. EKI-1526NL-CS | 1528NL-CS User Manual... -
Page 112: Chapter 9 Tcp And Udp Port Numbers
Chapter TCP and UDP Port Numbers... -
Page 113: List Of Known Tcp And Udp Port Numbers
(TCP) Telnet (TCP) SMTP (Mail Client) (TCP/UDP) (UDP) BOOTP Server/DHCP (UDP) BOOTP Client/DHCP (TCP) Web Interface/HTTP (TCP) (TCP) SNMP (TCP/UDP) SNMP Trap (TCP) HTTPS (TCP) Modbus/TCP (Default) (TCP) Syslog (TCP/UDP) DHCPv6 Client (TCP/UDP) DHCPv6 Server EKI-1526NL-CS | 1528NL-CS User Manual... - Page 114 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permission of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2022...
