EVAL-ADPDM3Z User Guide

EVALUATION BOARD SOFTWARE QUICK START PROCEDURES

INSTALLING THE APPLICATIONS WAVETOOL

Download the Applications Wavetool
EVAL-ADPDM3Z product page. Unzip the downloaded software
folder, run the enclosed Applications_Wavetool.exe file, and
follow the prompts for installing the
software (see Figure 2). For further information, follow the full
installation guide included with the
in the downloaded folder.
Figure 2. Applications Wavetool
To start the Applications Wavetool
Applications_Wavetool from the Start menu and click the
Applications_Wavetool icon (see Figure 3).
Figure 3. Navigate to Applications_Wavetool from Start Menu
At startup, the Applications Wavetool
checks if the installed Applications Wavetool
up to date. If a newer software version is available, the user is
prompted to download the newest version of the software.

EVALUATION BOARD USB CONNECTION

Prior to starting the Applications Wavetool
either the EVAL-ADPD2140Z
daughter board to the EVAL-ADPDM3Z evaluation board via the
board-to-board connectors (see Figure 4). Connect the EVAL-
ADPDM3Z evaluation board to a PC via the USB-C cable included
with the evaluation kit. The PC tries to find the device drivers
and install these drivers, if they have not been previously installed.
This search is done automatically. When the EVAL-ADPDM3Z
evaluation board is connected, open the
application (see Figure 5).
software package from the
Applications Wavetool
Applications Wavetool software
Setup
application, navigate to
application automatically
software version is
application, connect
or EVAL-ADPD1080Z-PRX
Applications Wavetool
Figure 4. EVAL-ADPDM3Z Evaluation Board
Figure 5. Applications Wavetool Window
After the Applications Wavetool
Connection > Connect to open the COM Port Selection
window. Select the appropriate communication (COM) port
from the Connect dropdown menu and click Connect (see
Figure 6). The Applications Wavetool
the EVAL-ADPDM3Z evaluation board is connected by
displaying M3 Motherboard Found on the screen.
Rev. 0 | Page 3 of 7
RESET BOOT
application opens, click
then acknowledges that
Figure 6. COM Port Selection Window
UG-1282
