Directed DIRECTECHS DS4+ Installation Manual page 19

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information
Function
Subaru Legacy (Smart Key) 2013-2014
Starter
Ignition 2
PTS
Ignition 1
Accessory
HS CAN 2 High
HS CAN 2 Low
HS CAN 1 High
HS CAN 1 Low
Parking Lights
Lock
Unlock
Trunk Release
Immo. Data
12V
19
Color Pin Polarity
Pink 7 (+)
Violet 9 (+)
White 28 (-)
Yellow 6 (+)
Red 4 (+)
Red 14 Data
White 15 Data
Red 20 Data
Blue 28 Data
Black/White 17 (-)
Brown/White 9 (-)
Brown/Black 20 (-)
Red 10 (-)
Red/White 25 Data
White 36 (+)
Connector Information
Location
Connector A - Keyless Access Module right of BCM.
Connector A - Keyless Access Module right of BCM.
Connector C - Keyless Access Module right of BCM.
Connector C - Keyless Access Module right of BCM.
Connector C - Keyless Access Module right of BCM.
Connector C - Keyless Access Module right of BCM.
Connector C - Keyless Access Module right of BCM.
BCM right of steering column.
BCM right of steering column.
BCM right of steering column.
BCM right of steering column.
BCM right of steering column.
BCM right of steering column.
ECM behind glovebox.
Relay holder behind dash fuse box.
Color Pins Ref.
White 18 A
White 18 A
White 30 B
White 30 B
White 30 B
White 30 B
White 30 B
White 35 C
White 35 C
White 35 C
White 35 D
White 35 D
White 35 D
White 35 E
White 44 F
DS4+ SUBARU3
