Directed DIRECTECHS DS4+ Installation Manual page 24

Module programming – Error codes
LED Description
CAN2 not detected.
Flashes red x 1
J1850 not detected.
Flashes red x 1
CAN1 not detected.
Flashes red x 2
Bypass data not detected.
Flashes red x 3
Bypass processing error.
Flashes red x 4
ISO 1 not detected.
Flashes red x 5
ISO 2 not detected.
Flashes red x 6
MUX not detected.
Flashes red x 7
Ignition not detected.
Flashes red x 9
External module synchronization
LED Description
OBDII feature not supported.
(Flashes red, red,
then orange) x 10
Active Ground When Running (Status)
LED Description
Ground When Running (Status) command
received.
Flashes green
Ignition ON command received.
Flashes red &
orange
Start ON command received.
Flashes green
quickly
PTS shutdown error.
Flashes red x 10
CAN bus incorrectly detected.
Flashes red x 21
Commands
LED Description
LOCK command received.
Flashes orange x 1
UNLOCK command received.
Flashes orange x 2
TRUNK command received.
Flashes orange x 3
AUX1 command received.
Flashes orange x 4
AUX2 command received.
Flashes orange x 5
AUX3 command received.
Flashes orange x 6
24
Troubleshooting
Check the CAN2 Orange/Green and Orange/Brown wire connections. Wake up the data bus
by turning the ignition on and try again. If your installation does not require this connection, skip
this step by pressing the programming button 5 times.
Check the J1850 wire connection. Wake up the data bus by turning the ignition on and try
again.
Check the CAN1 Tan and Tan/Black wire connections. Wake up the data bus by turning the
ignition on and try again. If your installation does not require this connection, skip this step by
pressing the programming button 5 times.
Check the bypass line connection. If more than one wire is used, make sure they are not inverted.
Ensure the vehicle still operates correctly using the factory key.
The bypass calculation failed. Reset the module and try again. If the condition persists, please
contact Technical Support.
The Yellow/Black wire did not detect the expected signal. Refer to "Installation (wiring diagrams,
fuse selection & vehicle wiring reference charts)" on page 8 to check the connections.
The Orange/Black wire did not detect the expected signal. Refer to "Installation (wiring diagrams,
fuse selection & vehicle wiring reference charts)" on page 8 to check the connections.
The Violet/Green or Violet/Brown wire did not detect the expected voltage value. Refer to
"Installation (wiring diagrams, fuse selection & vehicle wiring reference charts)" on page 8 to
check the connections.
Check the ignition input connection.
Troubleshooting
The diagnostic data bus was not detected, therefore the SmartStart features will be limited.
Troubleshooting
The module has initialized the remote start sequence.
The module has received the Ignition ON command and is processing the remote start sequence.
The module has received the Start ON command and is processing the remote start sequence.
The PTS output from the module was not activated due to safety protection.
Verify the CAN1 and CAN2 connections. Refer to "Installation (wiring diagrams, fuse selection &
vehicle wiring reference charts)" on page 8 to check the connections.
Troubleshooting
If the bypass module fails to flash, it did not receive the signal.
Commands can come from RF or D2D.
DS4+ SUBARU3
