Once the configuration is completed, reconnect the unit to the vehicle. The LED turns ON
7
solid green for 3 seconds once the module is successfully programmed.
Pair remotes (if applicable). For information on how to pair a specific remote, please
8
refer to its corresponding owner documentation, which can be found inside the product
packaging of the complete system or on www.directechs.com.*
By default, the tachometer is preprogrammed for the vehicle. For instructions on how to
9
program tach, see page 27.
* Your aftermarket remote may differ from the model shown in the illustrations.
You have successfully completed the module programming sequence.

LED diagnostics and troubleshooting

This section provides LED diagnostics and troubleshooting information to guide you through the various stages of your installation.
Module programming
LED Description
Module has no power.
Off
Waiting to begin the programming
sequence.
Solid red
Initialization failed.
Flashes green
& red
Transponder functions were skipped.
Solid orange
All required CAN networks has been
detected.
Flashes green
1 of 2 CAN networks has been detected.
Flashes orange
Key2GO initiated.
Flashes orange
slowly
Module was successfully programmed
Solid green x
with all functions.
3 secs
Module was successfully
programmed without transponder
Solid orange x
functions.
3 secs
23
Troubleshooting
Make sure the D2D harness is connected and that 12 Volt is present between the red and black
wires. If 12 Volt is present, the module may be defective.
Ensure the correct programming procedure is being followed.
Reset the module and complete the programming again. If the issue persists, please contact
Technical Support.
(If compatible) when RXT mode is not desired or convenience features are needed, please reset
the and reprogram the module.
Normal operation.
Normal operation.
Please follow the steps indicated in "Module programming" on page 22 to complete the
Key2GO programming.
Normal operation.
Normal operation.
Solid
x 3 secs
Pair
remotes*
Initialize
tachometer
DS4+ SUBARU3
