Directed DIRECTECHS DS4+ Installation Manual page 14

Wire Information
Function
Subaru XV Crosstrek/Crosstrek (Smart Key) 2014-2015
12V
HS CAN 1 High
HS CAN 1 Low
Starter
Ignition 2
Parking Lights
Lock
Unlock
PTS
Ignition 1
Accessory
HS CAN 2 High
HS CAN 2 Low
Immo. Data
Trunk Release
Subaru XV Crosstrek/Crosstrek Hybrid (Smart Key) 2014-2015
12V
HS CAN 1 High
HS CAN 1 Low
Starter
Ignition 2
Parking Lights
Lock
Unlock
PTS
Ignition 1
Accessory
HS CAN 2 High
HS CAN 2 Low
Immo. Data
Trunk Release
Keyless Access Module
2
10 9 8 7 6 5 4 3
18 17 16 15 14 13 12
A
14
Color Pin Polarity
Red 6
Red 6 Data
Blue 14 Data
Pink 7
Lt. Blue 9
Black/Blue 18
Lt. Gree/Black 15
Blue/Black 16
Black 30
Violet 6
Blue 4
White 14 Data
Blue 15 Data
Red/Yellow or
25 Data
Yellow
Yellow/Blue 10
Red 6
Red 6 Data
Blue 14 Data
Pink 7
Lt. Blue 9
Black/Blue 18
Lt. Gree/Black 15
Blue/Black 16
Black 30
Violet 6
Blue 4
White 14 Data
Blue 15 Data
Red/Yellow or
25 Data
Yellow
Yellow/Blue 10
1 4 3 2 1 6 5 4
16 1514 131211 10 9 8 7 6 5 18 17 16 151413 121110
11 282726 252423 222120 191817 30 2928 272625 242322 212019
B C
Location
(+) Back of fuse box.
OBDII.
OBDII.
(+) Connector A - Keyless Access Module right of BCM.
(+) Connector A - Keyless Access Module right of BCM.
(-) Headlight switch.
(-) Junction connector drivers kick panel.
(-) Junction connector drivers kick panel.
(-) Connector C - Keyless Access Module right of BCM.
(+) Connector C - Keyless Access Module right of BCM.
(+) Connector C - Keyless Access Module right of BCM.
Connector C - Keyless Access Module right of BCM.
Connector C - Keyless Access Module right of BCM.
ECM behind glove box.
(-) BCM under drivers dash.
(+) Back of fuse box.
OBDII.
OBDII.
(+) Connector A - Keyless Access Module right of BCM.
(+) Connector A - Keyless Access Module right of BCM.
(-) Headlight switch.
(-) Junction connector drivers kick panel.
(-) Junction connector drivers kick panel.
(-) Connector C - Keyless Access Module right of BCM.
(+) Connector C - Keyless Access Module right of BCM.
(+) Connector C - Keyless Access Module right of BCM.
Connector C - Keyless Access Module right of BCM.
Connector C - Keyless Access Module right of BCM.
ECM behind glove box.
(-) BCM under drivers dash.
3 2 1
9 8 7
Connector Information
Color
Brown
White
White
White
White
White
White
White
White
White
White
White
White
White
White
Brown
White
White
White
White
White
White
White
White
White
White
White
White
White
White
© 2017-09-26 Directed. All rights reserved.
Pins Ref.
9 A
16 B
16 B
18 C
18 C
20 D
28 E
28 E
30 F
30 F
30 F
30 F
30 F
35 H
35 G
9 A
16 B
16 B
18 C
18 C
20 D
28 E
28 E
30 F
30 F
30 F
30 F
30 F
35 H
35 G
DS4+ SUBARU3
