Directed DIRECTECHS DS4+ Installation Manual page 11

Locating components in the vehicle
Forester 2.5i (Smart Key) and
WRX STi (Smart Key) ECM Conn.
7 6 5 4 3
19 18 17 1615
27 26
35 34
Immo. Data
Keyless Access Module
2
10 9 8 7 6 5 4 3
18 17 16 15 14 13 12
A
11
ECM behind glove box
white 35 pin plug (B)
immobilizer serial
communcation
white/blue (data)
2 1
14 13 121110 9 8
25 24 23 22 21 20
33 32 31 30 29 28
1 4 3 2 1 6 5 4
16 1514 131211 10 9 8 7 6 5 18 17 16 151413 121110
11 282726 252423 222120 191817 30 2928 272625 242322 212019
B C
immobilizer serial
communcation
green/black (data)
Forester XT (Smart Key) and
WRX (Smart Key) ECM Conn.
12 12 11 11
10 10 9 9 8 8 7 7 6 6
24 24 23 23
22 22 21 21 20 20 19 19 18 18
36 36 35 35
34 34 33 33 32 32 31 31 30 30
48 48 47 47
46 46 45 45 44 44 43 43 42 42
Immo. Data
3 2 1
9 8 7
ECM on passenger fender
or ECM next to air cleaner
assembly black 48 pin plug
5 5 4 4 3 3 2 2 1 1
17 17 16 16 15 15 14 14 13 13
29 29 28 28 27 27 26 26 25 25
41 41 40 40 39 39 38 38 37 37
© 2017-09-26 Directed. All rights reserved.
DS4+ SUBARU3
