Features
•
STM32H753XIH6 microcontroller with 2 Mbytes of Flash memory and 1 Mbyte of RAM
in TFBGA240+25 package
• 5.7" 640x480 TFT-color LCD with touch screen
• Ethernet compliant with IEEE-802.3-2002
•
USB OTG HS and FS
2
•
I C compatible serial interface
•
RTC with rechargeable backup battery
•
SAI Audio DAC
•
ST-MEMS digital microphones
•
8-Gbyte (or more) SDIO3.0 interface microSD
•
8Mx32-bit SDRAM, 1Mx16bit SRAM and 8Mx16-bit NOR Flash
•
1 1-Gbit Twin Quad-SPI NOR Flash memory or two 512Mb Quad-SPI NOR Flash
memories
•
Potentiometer
•
4 colored LEDs
•
Reset, wakeup, tamper or key buttons
•
Joystick with 4-direction control and selector
•
Board connectors
– Power jack
– 3 USB with Micro-AB
– RS-232 communications
– Ethernet RJ45
– FD-CAN compliant connection
– Stereo headset jack including analog microphone input
– 2 audio jacks for external speakers
™
– microSD card
– JTAG/SWD and ETM trace
•
Board expansion connectors:
– Extension connectors and memory connectors for daughterboard or wire-wrap
board
•
Flexible power-supply options: ST-LINK USB V
•
On-board ST-LINK/V2-1 debugger/programmer with USB
re-enumeration capability: mass storage, virtual COM port and debug port
•
Comprehensive free software libraries and examples available with the STM32Cube
package
™
card
BUS
DocID030512 Rev 1
or external sources
