Eliwell ICPlus 915 Manual page 24

PAR. DESCRIPTION
Press the ESC, UP and DOWN keys (if configured for a second function) for the
H02 time H02 to activate the function itself.
N.B.: The AUX function has a fixed activation time of 1 second.
Lower input current/voltage limit.
H03
(only present on model V/I)
Upper current/voltage limit for input.
H04
(only present on model V/I)
Window filter:
H05
-2 = very fast; -1 = fast; 0 = normal; 1 = slow; 2 = very slow.
Key or Digital Input with aux/light or door switch active with the device OFF (but
H06
powered). n (0) = not active; y (1) = active.
Stand-by operating mode.
H08 0 = only display switches off; 1 = display on and controllers locked;
2 = display off and controllers locked.
Delay for output activation after Power On. If H10 = 0 the delay is NOT active; if
H10
H10 ≠ 0 the output will not be activated before this time has expired.
Digital Input Configuration.
0 = disabled; 1 = SOFT START; 2 = Offset setpoint; 3 = Outputs stopped;
H11
4 = Periodic cycle; 5 = AUX; 6 = Stand-by; 7 = Not used;
8 = External alarm; 9 = External alarm to lock regulators.
Polarity and priority of Digital Inputs (D.I.).
H13 no (0) = normally open; nc (1) = normally closed;
noP (2) = normally open with priority; ncP (3) = normally closed with priority.
H14 Digital input activation delay.
MODEL RANGE VALUE M.U. LEVEL
ALL 0...15
NTC/PTC
PT100-Tc
V/I -1999...1999
NTC/PTC
PT100-Tc
V/I -1999...1999
ALL -2/-1/0/1/2
ALL n/y
ALL 0/1/2
ALL 0...250
NTC/PTC 0..9
PT100-Tc
0...9
V/I
NTC/PTC no/nc/noP/ncP
PT100-Tc no/nc/noP/ncP
V/I
NTC/PTC 0...250
PT100-Tc 0...250
V/I
5 secs Inst
User/Inst
0 num
User/Inst
1000 num
0 num Inst
y flag Inst
2 num Inst
0 min Inst
0 num
0 num Inst
no num
no num Inst
0 min
0 min Inst
