Eliwell ICPlus 915 Manual page 23

PAR. DESCRIPTION
Calibration 1. Positive or negative temperature value added to the value read by
CA1
Pb1, according to the setting of parameter CAI.
Intervention of the offset on display, temperature control or both.
0 = only the temperature shown is modified;
CAI 1 = sum with only the temperature used by the controllers and not for the
display, which remains unchanged;
2 = sum with the displayed temperature, which is also used by the regulators.
LdL Minimum value that can be displayed by the device.
HdL Maximum value that can be displayed by the device.
Select the unit of measurement of probe 1.
• NTC/PTC: C (0) = °C, F (1) = °F
dro • PT100-Tc: C (0) = °C, F (1) = °F
• V/I: n (0) = no unit of measure selected,
t (1) = temperature, P (2) = pressure, H (3) = humidity
CONFIGURATION (folder 'CnF')
Probe type selection.
• NTC/PTC: Ptc (0) = PTC, ntC (1) = NTC
H00 • PT100-Tc: Jtc (0) = TcJ, Htc (1) = Tck, Pt1 (2) = PT100.
• V/I: 420 (0) = 4...20mA, 020 (1) = 0...20mA, t10 (2) = 0...10V,
t05 (3) = 0...5V, t01 (4) = 0...1V.
Output link:
H01
0 = independent; 1 = dependent; 2 = Neutral Zone (or window).
If one or more parameters are changed, the controller MUST be switched off and switched on again.
MODEL RANGE VALUE M.U. LEVEL
NTC/PTC -30.0...30.0
PT100-Tc -30.0...30.0
V/I -30...30
ALL 0/1/2
NTC/PTC -199.9...HdL
PT100-Tc -328...HdL -199.9
V/I -199...HdL
NTC/PTC LdL...199.9
PT100-Tc LdL...1350
V/I LdL...199
NTC/PTC C/F
PT100-Tc C/F
V/I n/t/P/H
NTC/PTC
Ptc/ntC
PT100-Tc Jtc/Htc/Pt1
420/020
V/I
t10/t05/t01
ALL 0/1/2
0.0 °C/°F
0.0 °C/°F User/Inst
0 num
2 num Inst
-50.0 °C/°F
°C/°F Inst
-199 num
140.0 °C/°F
1350 °C/°F Inst
199 num
C flag
C flag Inst
n num
ntc flag
Jtc num
User/Inst
420 num
0 num Inst
