PAR. DESCRIPTION
OUT2 activation differential. The utility stops on reaching the SP2 value
dF2 (as indicated by control probe) and restarts at a temperature value equal to
T=SP2+dF2 relative to HC2.
HS2 Maximum value assignable to setpoint SP2.
LS2 Minimum value assignable to setpoint SP2.
Maximum temperature alarm on OUT2.
HA2
(See 'Max/Min temperature alarms')
Minimum temperature alarm on OUT2.
LA2
(See 'Max/Min temperature alarms')
Switch-on delay. The indicated time must elapse between the request for
dn2
activation of the controller 2 relay and switch-on. 0 = not active.
Delay time after switching off. The indicated time must elapse between
dO2
deactivation of the controller 2 relay and the next switch-on. 0 = not active.
Delay between switch-ons. The indicated time must elapse between two
di2
consecutive switch-ons of regulator 2. 0 = not active.
Switch-off delay. The indicated time must elapse between the request for
dE2
deactivation of the controller 2 relay and switch-off. 0 = not active.
Controller 2 switch-on time in the event of faulty probe.
On2 if On2=1 and OF2=0, the controller remains on;
if On2=1 and OF2>0, the controller operates in Duty Cycle mode.
MODEL RANGE VALUE M.U. LEVEL
NTC/PTC 0.0...30.0
PT100-Tc 0.0...30.0
V/I 0...30
NTC/PTC
PT100-Tc LS2...HdL
V/I
NTC/PTC
PT100-Tc LdL...HS2
V/I
NTC/PTC
LA2...150.0
PT100-Tc
LA2...1999
V/I
LA2...150
NTC/PTC -150.0...HA2
PT100-Tc -328...HA2
V/I -150...HA2
ALL 0...250
ALL 0...250
ALL 0...250
ALL 0...250
ALL 0...250
1.0 °C/°F
1.0 °C/°F User/Inst
1 num
140.0 °C/°F
1350 °C/°F User/Inst
199 num
-50.0 °C/°F
-199.9 °C/°F User/Inst
-199 num
140.0 °C/°F
1350 °C/°F User/Inst
150 num
-50.0 °C/°F
-199.9 °C/°F User/Inst
-150 num
0 min Inst
0 min Inst
0 min Inst
0 min Inst
0 min Inst
