PAR. DESCRIPTION
Minimum temperature alarm on OUT1.
LA1
(See 'Max/Min temperature alarms')
Switch-on delay. The indicated time must elapse between the request for
dn1
activation of the controller 1 relay and switch-on. 0 = not active.
Delay time after switching off. The indicated time must elapse between
dO1
deactivation of the controller 1 relay and the next switch-on. 0 = not active.
Delay between switch-ons. The indicated time must elapse between two
di1
consecutive switch-ons of regulator 1. 0 = not active.
Switch-off delay. The indicated time must elapse between the request for
dE1
deactivation of the controller 1 relay and switch-off. 0 = not active.
Controller 1 switch-on time in the event of faulty probe.
On1 if On1=1 and OF1=0, the controller remains on;
if On1=1 and OF1>0, the controller operates in Duty Cycle mode.
Controller 1 switch-off time in the event of faulty probe.
OF1 if OF1=1 and On1=0, the controller remains off;
if OF1=1 and On1>0, the controller operates in Duty Cycle mode.
CONTROLLER 2 (folder 'rE2')
This sets the controller 2 operating mode.
HC2
H (0) = Hot; C (1) = Cold.
OS2 Temperature value to be added to SP2 if reduced set enabled
Operating band 2.
db2
(See 'ON/OFF regulation diagram')
MODEL RANGE VALUE M.U. LEVEL
NTC/PTC
-150.0...HA1
PT100-Tc -328...HA1 -199.9
V/I -150...HA1
ALL 0...250
ALL 0...250
ALL 0...250
ALL 0...250
ALL 0...250
ALL 0...250
ALL H/C
NTC/PTC -30.0...30.0
PT100-Tc
-30.0...30.0
V/I -30...30
NTC/PTC 0.0...30.0
PT100-Tc
0.0...30.0
V/I 0...30
-50.0 °C/°F
°C/°F User/Inst
-150 num
0 min Inst
0 min Inst
0 min Inst
0 min Inst
0 min Inst
1 min Inst
H flag Inst
0.0 °C/°F
0.0 °C/°F Inst
0 num
1.0 °C/°F
1.0 °C/°F Inst
1 num
