2. Scroll to parameter group 5-1* Digital Inputs and
press [OK].
14.7%
Digital In/Out
5-0* Digital I/O mode
5-1* Digital Inputs
5-4* Relays
5-5* Pulse Input
Figure 5.10
3. Scroll to 5-10 Terminal 18 Digital Input. Press [OK]
to access function choices. The default setting
Start is shown.
14.7%
Digital Inputs
5-10 Terminal 18 Digital
Input
[8]] Start
Figure 5.11
5.4 International/North American Default
Parameter Settings
Setting 0-03 Regional Settings to [0] International or [1]
North America changes the default settings for some
parameters. Table 5.1 lists those parameters that are
effected.
Parameter International
default parameter
value
0-03 Regional International
Settings
1-20 Motor Power See Note 1
[kW]
1-21 Motor Power See Note 2
[HP]
1-22 Motor Voltage 230 V/400 V/575 V
1-23 Motor 50 Hz
Frequency
3-03 Maximum 50 Hz
Reference
3-04 Reference Sum
Function
VLT ® AutomationDrive Instruction
Manual
0.00A 1(1)
4-13 Motor Speed
5-**
High Limit [RPM]
See Note 3 and 5
4-14 Motor Speed
High Limit [Hz]
See Note 4
4-19 Max Output
Frequency
4-53 Warning Speed
High
5-12 Terminal 27
Digital Input
5-40 Function Relay No operation
6-15 Terminal 53
0.00A 1(1)
High Ref./Feedb.
5-1* Value
6-50 Terminal 42
Output
14-20 Reset Mode
Note 1: 1-20 Motor Power [kW] is only visible when 0-03 Regional
Settings is set to [0] International.
Note 2: 1-21 Motor Power [HP] , is only visible when 0-03 Regional
Settings is set to [1] North America.
Note 3: This parameter is only visible when 0-02 Motor Speed Unit is
set to [0] RPM.
Note 4: This parameter is only visible when 0-02 Motor Speed Unit is
set to [1] Hz.
Note 5: The default value depends on the number of motor poles. For
a 4-pole motor, the international default value is 1,500 RPM, and for
a 2-pole motor, 3,000 RPM. The corresponding values for North
America are 1,800 and 3,600 RPM, respectively.
North American
default parameter
Changes made to default settings are stored and available
value
for viewing in the quick menu along with any
North America
programming entered into parameters.
See Note 1
See Note 2
208 V/460 V/575 V
60 Hz
60 Hz
External/Preset
®
MG33AL22 - VLT is a registered Danfoss trademark
Parameter International
default parameter
value
1,500 RPM
50 Hz
132 Hz
1,500 RPM
Coast inverse
50
No operation
Manual reset
Table 5.1 International/North American Default Parameter Settings
1. Press [Quick Menu].
2. Scroll to Q5 Changes Made and press [OK].
25.9%
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q5 Changes Made
Q6 Loggings
Figure 5.12
North American
default parameter
value
1,800 RPM
60 Hz
120 Hz
1,800 RPM
5
External interlock
No alarm
60
Speed 4-20 mA
Infinite auto reset
0.00A 1(1)
5-3
5
