Programming
53
6-1*
U - I
A53
55
Figure 5.10 Wiring Example for External Device Providing 0–10 V
Control Signal
5.3 Control Terminal Programming
Examples
Control terminals can be programmed.
•
Each terminal has specified functions it is capable
of performing.
•
Parameters associated with the terminal enable
the function.
•
For proper adjustable frequency drive
functioning, the control terminals must be
wired properly
programmed for the intended function
receiving a signal
See Table 5.1 for control terminal parameter number and
default setting. (Default setting can change based on the
selection in 0-03 Regional Settings).
The following example shows accessing Terminal 18 to see
the default setting.
1. Press [Main Menu] twice, scroll to parameter
group 5-** Digital In/Out and press [OK].
14.6%
Main Menu
2-** Brakes
3-** Reference / Ramps
4-** Limits / Warnings
5-** Digital In/Out
Figure 5.11
®
VLT Automation Drive D-Frame
Instruction Manual
+
0-10V
5.4 International/North American Default
Setting 0-03 Regional Settings [0] International or [1] North
America changes the default settings for some parameters.
Table 5.1 lists those parameters that are affected.
0-03 Regional
Settings
0-71 Date Format
0-72 Time Format
1-20 Motor Power
[kW]
0.00A 1(1)
1-21 Motor Power
[HP]
1-22 Motor Voltage 230 V/400 V/575 V
1-23 Motor
Frequency
3-03 Maximum
Reference
3-04 Reference
Function
®
MG34U222 - VLT is a registered Danfoss trademark
2. Scroll to parameter group 5-1* Digital Inputs and
press [OK].
14.7%
Digital In/Out
5-0* Digital I/O mode
5-1* Digital Inputs
5-4* Relays
5-5* Pulse Input
Figure 5.12
3. Scroll to 5-10 Terminal 18 Digital Input. Press [OK]
to access function choices. The default setting
Start is shown.
14.7%
Digital Inputs
5-10 Terminal 18 Digital
Input
[8]] Start
Figure 5.13
Parameter Settings
Parameter International
default parameter
value
International
DD-MM-YYYY
24 h
See Note 1
See Note 2
50 Hz
50 Hz
Sum
0.00A 1(1)
5-**
5
0.00A 1(1)
5-1*
North American
default parameter
value
North America
MM/DD/YYYY
12 h
See Note 1
See Note 2
208 V/460 V/575 V
60 Hz
60 Hz
External/Preset
5-3
