Installation and
Operation
This section describes the AXI 02 AT rear panel connections and front panel controls. The
following topics are covered:
•
•
•
•

Mounting

The 1U high, eighth-rack width, 4.42-inch deep AXI 02 AT mounts in the following manners:
•
•
•
NOTE: To mount the AXI 02 AT using an Extron ZipClip 100 mounting kit, see the
Mounting
Rear Panel Connections
Front Panel Features
Reset Modes
Rack mounting — Attach the device to a standard 19 inch rack shelf. The following
Underwriters Laboratories (UL) guidelines pertain to the installation of the AXI 02 AT in a
rack:
Reduced air flow — Install the equipment in the rack so that the amount of air
•
flow required for safe operation of the equipment is not compromised.
• Mechanical loading — Mount the equipment in the racks so that uneven
mechanical loading does not create a hazardous condition.
• Circuit overloading — When connecting the equipment to the supply circuit,
consider the effect that circuit overloading might have on overcurrent protection
and supply wiring. Consider equipment nameplate ratings when addressing this
concern.
Reliable earthing (grounding) — Maintain reliable grounding of rack-
•
mounted equipment. Pay particular attention to power supply connections other
than direct connections to the branch circuit (such as the use of power strips).
Under-furniture mounting — Mount the AXI 02 AT under the surface of a desk,
table, or podium.
Free-standing — Set the AXI 02 AT on furniture as desired.
instructions provided with the kit.
AXI 02 AT • Installation and Operation 3
