Introduction

This section provides an overview of this guide and the features of the Extron AXI 02 AT
Audio Expansion Interface. This section covers the following topics:
•
•
•
•

About this Guide

This guide contains installation, configuration, and operation information for the Extron
Electronics AXI 02 AT audio expansion interface. In this guide, the terms "AXI device,"
"device," and "AXI" are all used to refer to the AXI 02 AT interchangeably.

About the AXI 02 AT

The AXI 02 AT audio expansion interface is a Dante-to-analog converter in a 1U high,
eighth-rack width zip-clip enclosure. The AXI 02 AT is a Dante input, analog output interface
with an additional S/PIDF digital output. Analog outputs accept 3.5 mm captive screw
connectors. The RJ-45 PoE port on the front panel of the device provides two Dante
receiver channels and powers the device. Output attenuation and device settings are
configured with Extron DSP Configurator Software or SIS commands through DataViewer
or other control software. The AXI advertises itself on the Dante network and uses the
Dante Controller software for routing, device naming, channel naming, transmission latency,
sample rate, and IP communication settings.
NOTE: The AXI 02 AT may also be powered with an external power injector.

Features

•
•
•
•
•
About this Guide
About the AXI 02 AT
Features
Applications Diagrams
Receives two audio channels from a Dante
quality digital audio can be routed from the Dante network and converted to balanced
or unbalanced line level analog audio on a captive screw connector.
Mirrored two-channel analog and S/PDIF audio outputs — Audio is
provided as two line level analog outputs on captive screw connectors and a mirrored
two-channel S/PDIF output on a coaxial RCA connector.
Studio grade 24-bit digital-to-analog conversion with selectable
sampling rates up to 96 kHz — Professional converters fully preserve the integrity
of the original audio signal with selectable sampling rates via Dante Controller.
Power over Ethernet — Allows the AXI 02 AT to receive power and audio over a
single Ethernet cable, eliminating the need for a local power supply.
1U, eighth rack width enclosure, ZipClip™ 100 included — Compatible
with Extron Rack Shelves and ZipClip mounting solutions.
network — Two channels of high
®
AXI 02 AT • Introduction 1
