4.4.3 External Memory Interface (EMI) Connector, P3

Please refer to the schematics in
the pin-out of the EMI connector.

4.4.4 Analog Inputs Connector, P4

Analog input signals to the ADSP-21992 EZ-KIT Lite board are supplied at the analog inputs
connector (P4). Nominally, analog input signals in the range –1V to +1V may be applied to the
ADSP-21992 EZ-KIT Lite board.
PIN
ADSP-21992 EZ-KIT Lite Evaluation System Manual
NAME
1 +3.3V
2 DR
3 DGND
4 DT
5 NC
6 +3.3V
7 TCLK0
8 TFS
9 RFS
RCLK
Table 4-3: SPORT Connector, P2
APPENDIX A:
NAME
1 AGND
2 VIN0
3 VIN1
4 VIN2
5 VIN3
6 VIN4
7 VIN5
8 VIN6
9 VIN7
10 AGND
Table 4-4: Analog Input Connector, P4
SIGNAL
Vddext
Receive Data
Digital Ground
Transmit Data
No Connect
Vddext
Transmit Clock
Transmit Frame Sync
Receive Frame Sync
Receive Clock
SCHEMATICS, at the end of this document for
SIGNAL
Analog Ground
Analog Input Channel 0
Analog Input Channel 1
Analog Input Channel 2
Analog Input Channel 3
Analog Input Channel 4
Analog Input Channel 5
Analog Input Channel 6
Analog Input Channel 7
Analog Ground
