4 EZ-KIT LITE HARDWARE REFERENCE

4.1 Overview

This chapter describes the hardware design of the ADSP-21992 EZ-KIT Lite board. The
following topics are covered:

System Architecture

Describes the configuration of the DSP as well as all a description of how all of the
components on the board interface with the DSP.
Jumper Settings
Shows the location and describes the function of all the configuration jumpers.
Connectors
Shows the location and gives a description and pin-out of all connectors on the ADSP-
21992 EZ-KIT Lite board.
Mechanical Dimensions
Gives the physical dimensions of the ADSP-21992 EZ-KIT Lite board.
4.2 System Architecture
The ADSP-21992 EZ-KIT Lite board has been designed to provide access to all of the
capabilities of the ADSP-21992 DSP. This section describes the DSP's configuration on the EZ-
KIT Lite board.
ADSP-21992 EZ-KIT Lite Evaluation System Manual
(Section 4.2)
(Section 4.3)
4.4
(Section
)
4.5
(Section
)
4-28
