4.4.5 DAC Outputs Connector, P5
The outputs of the SPI DAC are brought out to the DAC outputs connector, P5.
PIN
1
2
3
4
5
6
7
8
9
10
4.4.6 Encoder Interface Connector, P6
Differential encoder signals can be applied to the ADSP-21992 EZ-KIT Lite board at the encoder
interface connector, P6.
PIN
1
2
3
4
5
6
7
8
9
10
ADSP-21992 EZ-KIT Lite Evaluation System Manual
NAME
AGND
DAC0
DAC1
DAC2
DAC3
DAC4
DAC5
DAC6
DAC7
AGND
Table 4-5: DAC Outputs Connector, P5
NAME
DGND
EIZ+
Differential North marker Z+
EIZ-
Differential North marker Z-
DGND
EIB+
Differential Quadr. Pulse input B+
EIB-
Differential Quadr. Pulse input B-
DGND
EIA+
Differential Quadr. Pulse input A+
EIA-
Differential Quadr. Pulse input A-
DGND
Table 4-6: Encoder Interface Connector, P6
SIGNAL
Analog Ground
DAC Channel 0
DAC Channel 1
DAC Channel 2
DAC Channel 3
DAC Channel 4
DAC Channel 5
DAC Channel 6
DAC Channel 7
Analog Ground
SIGNAL
Digital Ground
Digital Ground
Digital Ground
Digital Ground
4-42
