4.4.7 SPI Connector, P7

The SPI signals are made available at the SPI connector, P7.

4.4.8 Programmable Flag Interface Connector, P8

All programmable flag pins and the external ADC conversion start pin are available on the
programmable flag interface connector, P8.
PIN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
ADSP-21992 EZ-KIT Lite Evaluation System Manual
PIN NAME
1 DGND
2 SCK
3 MISO
4 MOSI
5 DGND
6 DGND
Table 4-7: SPI Connector, P7
NAME
+3.3V
PF0
PF1
PF2
PF3
PF4
PF5
PF6
PF7
DGND
PF8
PF9
PF10
PF11
PF12
PF13
PF14
PF15
CONVST
DGND
Table 4-8: Programmable Flag Interface Connector, P8
SIGNAL
Digital Ground
Clock
Master In Slave Out
Master Out Slave In
Digital Ground
Digital Ground
SIGNAL
Vddext
Programmable Flag 0
Programmable Flag 1
Programmable Flag 2
Programmable Flag 3
Programmable Flag 4
Programmable Flag 5
Programmable Flag 6
Programmable Flag 7
Digital Ground
Programmable Flag 8
Programmable Flag 9
Programmable Flag 10
Programmable Flag 11
Programmable Flag 12
Programmable Flag 13
Programmable Flag 14
Programmable Flag 15
ADC external convert start
Digital Ground
4-43
