Figure 2-14: Completing Driver - Analog Devices ADSP-21992 EZ-KIT LITE Manual

7. Click Next.
Windows 2000 will automatically install the driver. The driver installation is now complete as
shown in Figure
Figure 2-14: Completing Driver Installation Dialog Box
8. Click Finish to exit the wizard.
9. Verify the installation by following the instructions in section 2.4.5.
2.4.4.3 Windows XP USB Driver Installation
The Windows XP USB driver must first be installed before using the ADSP-21992 EZ-KIT Lite
evaluation system for the first time.
1. Insert the VisualDSP++ CD-ROM into the CD drive.
The connection of the device to the USB port will activate the Windows XP Found New
Hardware Wizard as shown in
ADSP-21992 EZ-KIT Lite Evaluation System Manual
2-14.
Figure 2-15.
2-18
