1. Remove the ADSP-21992 EZ-KIT Lite board from the package. Be careful when handling
the board to avoid the discharge of static electricity, which may damage components.
2. Table 2-2 shows the start-up default jumper settings. All other jumpers are not configured.
For the configuration of the jumpers on the ADSP-21992 EZ-KIT Lite board, refer to the
jumper settings in section, 4-35. Confirm that your board is set up in the default
configuration.
ADSP-21992 EZ-KIT Lite Evaluation System Manual
JUMPER POSITION
JP1 Closed – Ground Link
JP2 1-2 Position
JP3 1-2 Position
JP4 OPEN
JP5 2-3 Position
JP6 2-3 Position
JP7 2-3 Position
JP8 2-3 Position
JP12 CLOSED
JP15 CLOSED
JP16 CLOSED
JP24 CLOSED
Table 2-2: Start-up Default Jumper Settings
2-9
