6 Product overview

6 P
RODUCT OVERVIEW
6.1

Product description

The DynaGATE 10-06 is a Multi-service IoT Edge Gateway, designed to deliver LTE connectivity with
2G/3G fallback to automotive and lightly rugged applications.
It is based on the NXP i.MX 6UltraLite Cortex-A7 processor family, with 512MB of RAM, 4GB of eMMC,
and a user-accessible MicroSD and dual Micro-SIM slots.
The DynaGATE 10-06 offers the following wired connectivity capabilities: 2x Fast Ethernet, 2x CAN bus,
2x USB 2.0 for maintenance, 1x Ignition Key Input (surge protected), 1x Isolated Digital Input, 1x Isolated
Digital Output, 1x Isolated Odometer Input, 1x Isolated Forward Input; it also includes the following serial
ports (not isolated, surge protected): 1x RS-485, 1x RS-232.
1
It also offers a wide range of wireless connectivity capabilities : it can integrate an internal LTE Cat 1
modem (2G/3G fallback) with dual Micro-SIM support, 802.11 b/g/n Wi-Fi, and Bluetooth 4.2 BLE; an
internal 72-channel GNSS provides precise geolocation capabilities.
A rechargeable internal 2000 mA/h battery provides uninterrupted operation for up to 5 minutes in case of
power failure and permits a safe shutdown.
The DynaGATE 10-06 comes with a genuine Oracle Java SE Embedded 8 Virtual Machine and Everyware
Software Framework (ESF), a commercial, enterprise ready edition of Eclipse Kura, the open source
Java/OSGi middleware for IoT Edge Gateways.
Distributed and supported by Eurotech, ESF adds advanced security, diagnostics, provisioning, remote
access and full integration with Everyware Cloud (EC), Eurotech IoT Integration Platform (separately
available).
For further details visit www.eurotech.com.
Figure 6.1 - The DynaGATE 10-06 rear view
1
The features availability depends on the product versions
