DynaGATE 10-06 User manual Rev. 0-8
9.2.1.7
Second antenna requirements (for antenna diversity)
Feature
Impedance
Frequency range
Bands
Return Loss
Efficiency
Description
50 Ohm
The required frequency range of the antenna connected depends on the operating bands of
the used cellular module and the used mobile network.
See
"Bands support" on page 45
VSWR < 2:1 recommended
VSWR < 3:1 acceptable
> -1.5 dB ( > 70% ) recommended
> -3.0 dB ( > 50% ) acceptable
9 Features in detail
47 / 72
