Appendix References
Table 3: Related Documents
SN
Document Name
[1]
Quectel_EC21_Footprint&Part
[2]
Quectel_EC25_Footprint&Part
[3]
Quectel_EC20_R2.1_Footprint&Part
[4]
Quectel_EG25-G&EG21-G_Footprint&Part
[5]
Quectel_LTE_Module_Thermal_Design_Guide
Table 4: Terms and Abbreviations
Abbreviation
ADC
ESD
GPIO
I/O
LTE
PCB
PCM
PHY
RF
SD
EC2x&EG2x-G_Series_PCB_Design_Guideline
Description
Analog-to-Digital Converter
Electrostatic Discharge
General-Purpose Input/Output
Input/Output
Long Term Evolution
Printed Circuit Board
Pulse Code Modulation
Physical Layer
Radio Frequency
Secure Digital
LTE Standard Module Series
EC2x&EG2x-G Series PCB Design Guideline
Remark
EC21 series Footprint&Part
EC25 series Footprint&Part
EC20 R2.1 Footprint&Part
EG25-G&EG21-G Footprint&Part
Thermal design guide for LTE standard,
LTE-A and Automotive modules
