Installation, Operation and Maintenance Manual
MDE 256 Rev. 1
11.2.2

General Data

Slot 1, Index 0, length 4 byte: General data about current working condition
Byte
0
1
2
3
11.2.3

Maintenance Information

Slot 2, Index 0, length 22 byte: General maintenance information
Byte
8 - 11
12 - 15
16 - 19
20 - 21
Diagnosis - Alarms
Name
Byte 0
Byte 1
Byte 2
Byte 3
Name
0 - 1 Actuator position
2 - 3 Output torque
4 - 5 Opening time
6 - 7 Closing time
Contactor cycles
Motor Run Time
Time Without Power
Utilization Rate
bit Description
0 Close limit
1 Open limit
2 Moving
3 Monitor relay
4 Selector in local
5 Selector in remote
6 Alarm
7 Warning
0 DIN 1
1 DIN 2
2 DIN 3
3 DIN 4
4 DIN 5
5 DIN 6
6 Interlock open
7 Interlock close
0 Fail safe action
1 Opening
2 Closing
3 Selector in off
4 ESD active
5 HW remote mode
6 Positioner mode
7 Motion inhibited
0 Channel 1 active
1 Aux. in open
2 Aux. in close
3 Aux. in stop
4 Aux. in bus on
5 Reserved
6 Reserved
7 Reserved
Dim
2 byte
2 byte -100,+100
2 byte 0 - 65, 535
2 byte 0 - 65, 535
4 byte 0 - 4, 294, 967, 295
4 byte 0 - 4, 294, 967, 295
4 byte 0 - 4, 294, 967, 295
2 byte 0 - 65, 535
Section 11: Diagnosis - Alarms
April 2021
Range EU
0 - 1,000
Seconds
Seconds
Unit
Hours
Hours
%
51
