BIFFI ICON3000 Installation, Operation And Maintenance Manual page 51

Installation, Operation and Maintenance Manual
MDE 256 Rev. 1
Octet 5
Octet 6
Octet 7
Diagnosis - Alarms
bit0
Alarm_Data_ Description_0:
(1) = Motor Thermostat
(1) = HI-HI Torque in Opening
(1) = HI-HI Torque in Closing
(1) = Actuator blocked in Opening
(1) = Actuator blocked in Closing
(1) = HI-HI Temperature
(1) = Position Sensor Failure
(1) = Speed Sensor Failure
bit0
Status_Data_Description_1:
(1) = Main Voltage Fault
(1) = K1 Contactor Failure
(1) = K2 Contactor Failure
(1) = Configuration Error
(1) = Hardware Error
(1) = Low Alkaline Battery
(1) = Lost Phase
(1) = Communication base card to Primary card failure
bit0
Status_Partner_ Description:
(1) = Failure Communication base card to Backup card failure
(1) = Backup card RedCom TX Failure
(1) = Backup card RedCom RX Failure
(1) = Reserved
(1) = Reserved
(1) = Reserved
(1) = Reserved
(1) = Reserved
